Placing/removing a disc

The following are some notes on placing and/ or removing a disc.

<IMPORTANT!>

When placing a disc on the tray, support the tray from the bottom by your hand. If you push the disc to fit into the pivot on the tray without supporting the tray, the tray/drive may be dam- aged or broken. Also note that the disc must be pushed until it clicks so that it is locked into the pivot securely. Closing the tray without lock- ing the disc may damage the disc.

<Note for removing a disc from the tray>

When removing a disc from the tray, also sup- port the tray from the bottom by your hand. Also be careful not to unlock the disc from the pivot forcibly, which may damage the tray.

• Place the disc with the label side up.

When placing the disc, support the tray from the bottom by your hand as shown in the illustration below, and push the disc gently until it clicks so that the disc is locked into the pivot.

Push the disc until it clicks so that the disc is locked into the pivot.

disc

Support the tray from the bottom by your hand.

<Caution!>

Do not touch the lens when placing a disc or removing a disc, doing so may dam- aged may cause a malfunction.

5
