Docking Doors

Dell™ Inspiron™ 8500/8600 Service Manual

Removing the Docking Doors

CAUTION: Before working inside your computer, read the safety instructions in your Owner's Manual.

NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically touching an unpainted metal surface (such as the back panel) on the computer.

1.Follow the instructions in "Preparing to Work Inside the Computer."

2.Gently bend the docking covers and lift them away from the computer base.

Installing the Docking Doors

Slide the side of the docking covers with the spring over the longer posts.

Image 16
