Features & Specifications

CPU

Support AMD Athlon 64 Processor

Front Side Bus: 800MHz

Socket type: K8 Socket 754

Chipset

North Bridge: SiS755

South Bridge: SiS964(L)

AC’97 Audio Codec: ALC655

Memory

Module Speed: DDR 200/266/333/400

Socket Type: Two DDR 184-pin unbuffered DIMM sockets

Maximum Memory Size: 2GB

BIOS

BIOS Memory Size:2MB

Kernel:Award Kernel with Acer skin

PCI Slot

PCI Slots Quality: 3 pcs

PCI Slot Type:PCI 2.2 5V slot

AGP Slot

AGP Slot Type: AGP 8x 1.5V slot

AGP Slot Quality:1

Speed: 4x/8x

IDE

Headers: Two 40-pin IDE low profile headers

Devices: Up to 4 IDE devices

Speed: PIO mode ATA 66/100/133

Audio Connectors and Headers

Real Audio Connector: Line Out, Line In, Microphone In

One CD-In Header

One AUX In Header

One SPDIF Header

One Intel specification audio header

LAN

LAN Phy: RealTek RTL8201BL/CT 10/100 Mbs support

2

Chapter 1
