CONNECTIONS & SETUP

SET THE SAT/CABLE CHANNEL (AUTO TUNING)

The next step lets you set the SAT/CABLE channel. When you set the SAT/CABLE channel, you’re telling the monitor what channel to tune to when you press the DIRECTV button on the remote.

Indicate which input you used to connect a satellite receiver, a cable box or a digital set top converter. If you don’t have one of these components connected to the monitor, skip this step.

1.From the CHANNEL menu (shown below), select Auto Tuning.

CHANNEL

1 Signal Type

2 Auto Channel Search

3 List and Labels

4 Auto Tuning

0 Go Back

2.From the AUTO TUNING menu (shown below), select Set SAT/CABLE Channel.

AUTO TUNING

1 Set VCR1 Channel...

2 Set VCR2 Channel...

3 Set DVD Channel...

4 Set SAT/CABLE Channel...

0 Go Back

3.From the SET SAT/CABLE Channel menu (shown below), point to the choice in the that matches the way you have your satellite receiver or cable box connected to the monitor.

SET SAT/CABLE CHANNEL

1 Not connected 2 Channel 2

3 Channel 3

4 Channel 4

5 Video 1 Input

6 Video 2 Input

7 Video 3 Input

8 (S)VGA 2 Input

4.Press OK to select it.

24
