Setting the Starting Address

This DMX mode enables the use of a universal DMX controller device. Each fixture requires a start address from 1~512. A fixture requiring one or more channels for control begins to read the data on the channel indicated by the start address. For example, a fixture that uses six DMX channels and was addressed to start on DMX channel 100, would read data from channels: 100, 101, 102, 103, 104, and 105. Choose start addresses so that the channels used do not overlap, and note the start address selected for future reference.

If this is your first time addressing a fixture using the DMX control protocol, we suggest jumping to the “Appendix” section and reading the heading “DMX Primer”. It contains very useful information that will help you understand its use.

General Troubleshooting

SYMPTOM

POSSIBLE CAUSE(S)

POSSIBLE ACTION(S)

Breaker/Fuse

Excessive circuit load

Check total load placed on the electrical circuit.

Short circuit along the power

Check for a short in the electrical wiring (internal and/or

keeps blowing



wires

external)







Device does not

No power

Check for power on power outlet





power up

Loose power cord

Check power cord





Wrong DMX addressing

Check Control Panel and unit addressing



Damaged DMX cables

Check DMX cables

Fixture is not

Wrong polarity settings on the

Check polarity switch settings on the controller

controller

responding to



DMX

Loose DMX cables

Check cable connections





Faulty DMX interface

Replace DMX input



Faulty Main PCB

Replace Main PCB









Non DMX cables

Use only DMX compatible cables



Bouncing signals

Install terminator as suggested

Loss of signal

Long cable / Low level signal

Install amplifier right after fixture with strong signal







Too many fixtures

Install an optically coupled DMX splitter after unit #32



Interference from AC wires

Keep DMX cables separated from power cables or





black lights







If you still have a problem after trying the above solutions, please contact CHAUVET Technical Support.

Contact Us

World W ide

General Information

CHAUVET



3000 North 29th Court



Hollywood, FL 33020



voice:

954.929.1115



fax:

954.929.5560



toll free: 800.762.1084

Technical Support

CHAUVET



3000 North 29th Court



Hollywood, FL 33020



voice:

954.929.1115 (Press 4)



fax:

954.929.5560 (Attention: Service)

World Wide Web

www.chauvetlighting.com
