Toshiba WT10-A user manual Grand tour of the tablet Toshiba WT8-B

Page 37

Figure 3-3 Grand tour of the tablet (TOSHIBA WT8-B)

11

3

12

13

13

4

1

5

2

6

7

8

9

10

1.	Display screen	8.	Memory media slot
2.	Web Camera (front)	9.	Microphone
3.	Micro-USB port	10.		Strap hole for pen
4.	Windows button	11.		Web Camera (back)
5.	Headphone/Microphone combo jack	12.		Wireless communication antennas
		(not shown)
6.	Power button	13.		Speakers
7.	Volume up/down button

Product appearance depends on the model you purchased.

Display screen	20.3cm (8") LCD screen, configured with the
	following resolutions:
	HD, 800 horizontal x 1280 vertical pixels

Please be aware that, when the tablet is operating on the AC adaptor, the image displayed on the internal screen will be somewhat brighter than when it operates on battery power. This difference in brightness levels is intended to save power when operating on battery.

Legal Footnote (LCD)

For more information regarding LCD, please refer to the Legal Footnotes section.

Web Camera (front) Web Camera is a device that allows you to record video or take photographs with your tablet. You can use it for video chatting or video conferences using a communication tool.

User's Manual

3-6
