Toshiba WT10-A 3D Playback on an External 3D Device, Important Safety Information for 3D Function

Page 42

Swipe

Quickly move your finger in from the edge of the



screen, without pausing when you first touch it.



Swipe from the left edge: shows your recently



opened apps, and so on.



Swipe from the right edge: opens or closes the



charms (Search, Share, Start, Devices, Settings).



Swipe from the top edge: opens or closes the



app command bar.





For details and more advanced touch screen gestures to interact with Windows operating system, please refer to Help and Support.

Do not press or push with excess force on the touch screen. Do not apply excess force when cleaning the touch screen.

Never touch the screen with a sharp object such as a ball-point pen which may scratch or damage the surface.

Do not use a protecting sheet for the touch screen as it may decrease its sensitivity to gestures.

3D Playback on an External 3D Device

3D playback on an external 3D device feature is only provided with TOSHIBA WT10-A models.

Effect of 3D can be shown only on an external 3D devices connected via an HDMI output. It cannot be shown on the internal display. In order for 3D playback to work on external display/TV, you need a 3D enabled display/ TV that has an HDCP compliant HDMI port.

3D playback feature supports the following resolutions:1920x1080 24Hz and 1280x720 60Hz.

Please change the Screen Resolution to one of the above before using 3D playback function.

Important Safety Information for 3D Function

Please refrain from or stop viewing if you feel ill or experience discomfort before or while watching 3D video images.

Please refrain from viewing 3D video images if you experience convulsions, photosensitivity reaction, or heart disease.

Due to the possibility of impact on vision development, viewers of 3D video images should be aged 6 or older. Children and teenagers may be more susceptible to health issues associated with viewing in 3D and should be closely supervised to avoid prolonged viewing without rest.

User's Manual

4-2
