LoopStar® EtherNID™ – LoopStar® MetroNID™

ADC's network interface devices for Ethernet and IP networks

Features

Interfaces



EtherNID EE



Client

10/100Mbps, RJ-45(1)

Network:

10/100Mbps, RJ-45(1)

Monitor A/B Port:

2 x 10/100Mbps RJ-45(1)



Management port: 10/100Mbps, RJ-45(1)

EtherNID GE, MetroNID TE and MetroNID TE-R

Client/Network: Mix & Match Assignable Ports for Client, Network and Monitoring Functions

2 x 10/100/1000Mbps RJ-45(3)

2 x 10/100/1000Mbps SFP(4)

Monitor A/B port: Mix & Match with Client/Network Ports

Management Port:

10/100Mbps RJ-45(1)

GPS Antenna Input

SMA Connector (5)

MetroNID TE-S

Client/ Network: Mix & Match Assignable Ports for Client, Network and Monitoring Functions)

4 x 10/100/1000Mbps SFP(4)

Monitor A/B port: Mix & Match with Client/Network Ports

Management Port:

10/100Mbps RJ-45(1)

GPS Antenna Input

SMA Connector (5)

Service Assurance Features

Loopback functionality

Layer 1, Layer 2 (MAC Swap), Layer 3 (IP Swap), Layer 4 (TCP/UDP Port Swap)

Automatically reacts to in-band loopback requests sent from popular 3rd

party Ethernet test-sets, as well as 802.3ah / Y.1731 OAM loopback commands.

Loopback on specific VLANs, source/destination MAC/IP address(es), Ethertype, protocol type, service class, or any logical combination.

Loopback on specific MAC/IP source and/or destination address

Thru-traffic per-flow statistics

Stats per VLAN, per Ethertype, per ToS, per CoS, per MAC, per IP, etc.

Stores up to 7 days of local and remote historical packet statistics in user configurable history buckets (typically set from 1-15 minutes).

Monitor up to 60 concurrent flows on MetroNID TE-R, 16 flows on other units

Dual Monitor Access Ports providing individual access to both signal directions, combined access to both directions and intelligent filtering.

Up to 100Mpbs of traffic can be monitored from each port

Fast fault propagation <50 ms on all interfaces, client & network ports

Transparent fail-over bypass on electrical-to-electrical models

Dual protected uplink option for network side optical connection(5)

Link loss return

(1)10/100Mbps (10/100 Base TX) RJ-45 Connectors: supports Auto-negotiation and Auto MDIX

(2)100Mbps (100 Base FX/LX/SX/ZX/BX) SFP Connector: supports a wide range of SFPs

(3)10/100/1000Mbps (10/100/1000 Base TX) RJ-45 Connectors: supports Auto-negotiation and Auto MDIX

(4)10/100/1000Mbps (10/100/1000 Base TX/FX/LX/SX) SFP Connectors: supports a wide range of SFPs including copper SFPs

(5)Optional, available on MetroNID models only.

w w w . a d c . c o m

+ 1 - 9 5 2 - 9 3 8 - 8 0 8 0

1 - 8 0 0 - 3 6 6 - 3 8 9 1
