2.1.4 ASUS CrashFree BIOS 2 utility

The ASUS CrashFree BIOS 2 is an auto recovery tool that allows you to restore the BIOS file when it fails or gets corrupted during the updating process. You can update a corrupted BIOS file using the motherboard support CD, or the floppy disk that contains the updated BIOS file.

•Prepare the motherboard support CD, or the floppy disk containing

the updated motherboard BIOS before using this utility.

•Make sure that you rename the original or updated BIOS file in the floppy disk to P5GCMX.ROM.

Recovering the BIOS from a floppy disk

To recover the BIOS from a floppy disk:

1.Turn on the system.

2.Insert the floppy disk with the original or updated BIOS file to the floppy disk drive.

3.The utility displays the following message and automatically checks the floppy disk for the original or updated BIOS file.

Bad BIOS checksum. Starting BIOS recovery...

Checking for floppy...

If your display monitor is connected to the onboard VGA connector, the display monitor will turn-off and the system will beep once while the CrashFree BIOS 2 starts updating your system. The system will beep once again while the process is finished, and the display will return after the system restarts.

When found, the utility reads the BIOS file and starts flashing the corrupted BIOS file.

Bad BIOS checksum. Starting BIOS recovery...

Checking for floppy...

Floppy found!

Reading file “P5GCMX.ROM”. Completed.

Start flashing...

DO NOT shut down or reset the system while updating the BIOS! Doing so can cause system boot failure!

4.Restart the system after the utility completes the updating process.

2-	Chapter 2: BIOS setup
