Page 35

FEATURES menu

ENGLISH

BLUE BACK

You can set the TV to automatically change to a blue screen and mute the sound if the signal is weak or absent, or when there is no input from an external device.

ON:

This function is turned on.

OFF:

This function is turned off.

CHILD LOCK

You can disable the front control buttons of the TV. When this function is set to ON, the TV can be operated only by using the remote control.

Use this function to prevent children from operating the TV at their own discretion (without parent consent).

ON:

This function is turned on.

OFF:

This function is turned off.

When you disconnect the AC plug, the CHILD LOCK will be cancelled.

AUTO SHUTOFF

You can set the power to turn off if no signal is received and no operation is performed for about 15 minutes or longer after the end of a broadcast.

ON:

This function is turned on.

OFF:

This function is turned off.

•The AUTO SHUTOFF function does not turn off the TV’s main power.

•The AUTO SHUTOFF function does not work for the VIDEO mode or a picture from a PC signal.

REFRESH

When burn-in is minimal, burn-in and residual images may be softened with the REFRESH function.

1Choose REFRESH

2Press the a button

Snow appears on the screen. Leave the TV in this condition for a few hours.

3After a few hours, press the TV, number buttons, or # button

Press the Abutton for the TV.

The REFRESH function has no effect if used only for a short time.

FAVOURITE SETTING

Chose when deleting the favourite channels registered in the buttons 1 to 4.

1Choose FAVOURITE SETTING, then press the a or 3 button

The FAVOURITE SETTING menu appears.

FAVOURITE SETTING

1PR 01

2PR 02

3PR 03

4PR 04

RESET

OK

D0112-EN

2Press the 6 buttons and chose the favourite channel that you want to delete

3Press the blue button

The chosen favourite channel and set contents are deleted.

34
