Hitachi P42T501, P42T501A, P50T501, P50T501A, P55T551 Accessories, For U.S. models

Page 4
Lift up on tab to remove back cover.
CAUTION: Do not insert batteries with ‘+’ and ‘-’ polarities reversed as this may cause the batteries to swell or rupture resulting in leakage.
Bottom View (Remote Control)

Accessories

Check to make sure you have the following accessories before disposing of the packing material.

First time use

￿ Remote Control

￿ Two “AA” size,

￿ Power Cord



1.5V batteries



￿Table Top Stand

(50" included)

For U.S. models:

For optional accessories, please access our web site at:

www.hitachi.us/tv

￿Wire Clamp

(50" models only)

￿Table Top Stand (42” included)

Note: Please visit our website for optional accessories.

CAUTION: 1. Ceiling mounting is not recommended. Mounting the panel on the ceiling does not provide adequate ventilation for the electronics or proper support for the front glass panel. This plasma television product is designed for a maximum tilting angle of 45 degrees from vertical.

2.This stand for use only with Hitachi P42T501, P42T501A, P50T501 and P50T501A. Use with other apparatus is capable of resulting in instability causing possible injury.

3. The wall mount unit for the 50" and 42" models is WM07S and for the 55" models is WM07L. Please see page 7 & 8 for important information related to the wall mount. Wall Mount unit is an optional accessory (Not Included).

￿ Remote Control Unit CLU-4371A

￿ Wire Clamp (50" models only)

(Part No. HL02401).



￿Two "AA" size, 1.5V batteries.

￿Table Top Stand (UX27662 42" model) (UX27282 50" model).

￿Power Cord (P# EV01841).

REMOTE CONTROL BATTERY INSTALLATION AND REPLACEMENT

1.Open the battery cover of the remote control by pushing down and sliding the back cover off.

2.Insert two new “AA” size batteries for the remote control. When replacing old batteries, push them towards the

springs and lift them out.

3. Match the batteries to the (+) and (-) marks in the battery compartment.

4. Insert the bottom of the battery, the (-) side, into the battery compartment first, push towards the springs and insert the top of the battery, the (+) side, into place. Do not force the battery into the battery compartment.

5.Replace the cover.
