RCA VR525 manual VCR PLUS+ Channels, Two-Digit VCR Plus+ Channel Numbers for Cable TV USA List

Page 14

SETTING UP THE VCR

VCR PLUS+ CHANNELS

Using VCR Plus+ can make programming timer recordings for cable or off-air antenna easier, but you have to put in a little time right now to set up a channel list. A worksheet and abbreviated codes for typical cable services in the U.S. and Canada are provided.

1. Press MENU to display the VCR MAIN MENU.

VCR MAIN MENU

1 VCR Plus+

2 Timer Recordings

3Time

4Channels

5Preferences

6Language

0Exit

2.Press 4 to display the CHANNELS menu.

CHANNELS

1 Auto Channel Search

2 Add/Remove Channels

3 Signal Type: CABLE

4 VCR Plus+ Channel List

0Exit

3.Press 4 to display the VCR Plus+ Channel List screen.

VCR+ Channel My Channel

5 --

4--

3-> -> -> --

2	--
1	--

Use CH+/- to select

Press 0-9 to change

Press MENU to save

4.Enter the data following the on-screen directions using your worksheet.

VCR+ Channel My Channel

5 46

4--

3-> -> -> 23

2	--
1	--

Use CH+/- to select

Press 0-9 to change

Press MENU to save

Two-Digit VCR Plus+ Channel

Numbers for Cable TV

(USA List)

35American Movie Classics

39Arts &-Entertainment

57Black Entertainment

54Bravo

42Cable News Network

45Cinemax

98Cinemax 2

37The Discovery Channel

53The Disney Channel

63Entertainment Television

34ESPN Sports Network

47The Family Channel

33Home Box Office

95Home Box Office 2

96Home Box Office 3

51The Learning Channel

46Lifetime

58The Movie Channel

48Music Television

49The Nashville Network

38Nickelodeon

64Nostalgia Television

99Quality Value Cable

41Showtime

97Showtime 2

59Sports Channel

52Turner Network Television

44USA-Network

62Video Hits 1

93Viewer’s Choice 1

94Viewer’s Choice 2

55WGN Chicago

43WTBS Atlanta

60WWOR-New York

See next page for Canadian List

VCR Plus+ Channel List

Refer to your local television list for a complete VCR Plus+ channel list for your viewing area or contact your cable company. Using the list may save you some time.

12	Screen is for an example only.
