Page 20

SETUP MENU

The Setup menu provides access to various advanced features and also to the Tuning menu

Open the Setup menu

Move to your choice

Increase or decrease levels, set options or access further menus

Press the TV/AV button to exit the Setup menu

SET UP

TV/AV

	Select
	Change
TV/AV	Exit

Setup menu

Teletext	FASTEXT
Off timer	Off
Tuning menu

Teletext

Off timer

The Teletext option allows you to choose between FASTEXT or List mode. See page 38.

Off timer will switch the TV off within a preset time which you can choose from between 0 to 90 minutes in 15 minute intervals.

	Select
	Change
TV/AV	Exit

Setup menu

Teletext	List
Off timer	Off
Tuning menu

Tuning menu

Volume correc.

The Tuning menu provides an entry to many other features including Programme edit and Auto setup.

See page 21.

Volume correction (in AV mode only) allows you to adjust the volume level of individual stations.

	Select
	Change
TV/AV	Exit

Setup menu

Teletext	FASTEXT
Off timer	Off
Tuning menu

20
