Disc Playback

Settings During Playback

DISC MENU Control

This allows you to adjust various settings at once, like subtitles, angle settings and the title selection for Direct Playback. You can adjust the video and audio to suit your preferences. The operations are the same for BD and DVD.

DISC MENU control screen

1

BD-VIDEO





1 / 3









5 / 2

5







00 :

20 : 30





2 English





2

11



5 . 1ch





Off







3

Select

ENTER

Enter





RETURN

Return

1Playback status display

Shows the operation status and the disc type.

2Setting items

Selects a title or chapter for playback, or performs video/audio settings.

Title Number (Direct Title Skip)

Chapter Number (Direct Chapter Skip)

Playback Elapsed Time (Direct Time Skip)

Subtitle Language

Angle Number

Audio

Repeat

3Operation guide display

Provides help on remote control button operations.

DISC MENU Operation Procedure

1Press DISC MENU during playback.

The DISC MENU control screen is displayed.

2Press a/b to select the desired setting, and then press ENTER.

For a description of each setting, see “DISC MENU Which Can Be Set”.

3Press a/b/c/d to set, and then press ENTER.

Operations vary depending on the setting. Follow the operation instructions on the screen.

4Press RETURN or DISC MENU to close the DISC MENU control screen.

If “– –” is displayed for an option like title number or subtitles, the disc has no titles or subtitles which can be selected.

The displayed items vary depending on the disc.

If you access the DISC MENU control screen during playback of a BD/DVD-VIDEO, it may be impossible to operate the BD/DVD-VIDEO playback. In cases like this, close the DISC MENU control screen.

DISC MENU Which Can Be Set

Title Number (Direct Title Skip)

Shows the title number being played back. You can skip to the start of the title.

To skip to the start of a selected title, press 0-9to enter the title number when this option is highlighted.

Chapter Number (Direct Chapter Skip)

Shows the chapter number being played back. You can skip to the start of the chapter.

To skip to the start of a selected chapter, press 0-9to enter the chapter number when this option is highlighted.

Playback Elapsed Time (Direct Time Skip)

Shows the elapsed time from the beginning of the disc to the present. This lets you skip to a specifi c time.

Press c/d to select the Hour, Minute or Second, and then press a/b or 0-9to set the time. Press ENTER to start playback at the set time.

Subtitle Language

Shows the currently selected subtitle language. If subtitles are provided in other languages, you can switch to your preferred language.

Angle Number

Shows the currently selected angle number. If the video is recorded with multiple angles, you can switch the angle.

Audio

Shows the currently selected type of audio. You can select the desired type of audio.

Repeat

The current Title (or Chapter) or partial segments can be repeatedly played back.

These functions may not work with all discs.

29

Image 31
