Page 32

On-Screen Display Menu

Color Gamut Range

(For LC-80LE844U/LC-70LE847U/LC-60LE847U)

You can set the color gamut range.

Standard: Standard color gamut.

Expanded: More vivid colors with expanded color gamut.

"Color Gamut Range" is only available when AV MODE is set to "MOVIE" or "MOVIE (3D)".

Color Temp. (Color Temperature)

For a better white balance, use color temperature correction.

High: White with bluish tone

Mid-High:

Middle:

Mid-Low:

Low: White with reddish tone

White balance can be adjusted between a maximum of +30 and a minimum of –30 for each color temperature.

R Gain (LO/HI)/G Gain (LO/HI)/B Gain (LO/HI)

Fine tuning the color temperature

To fi ne tune the color temperature, set "10 Point Setting" to "On".

You can adjust the "Position" setting. Adjust the set color temperature from +1 to +10.

White balance can be adjusted between a maximum of +30 and a minimum of –30 for each color temperature.

When "Position" is set to "10", you can adjust the white balance between –30 and 0.

For resetting all adjustment items to the factory preset values, press a/b to select "Reset", and then press

ENTER.

Motion Enhancement

Use Motion Enhancement to view fast-action video more clearly.

LC-80LE844U

AquoMotion480: Turn the LED backlight on or off for 240Hz drive display.

AquoMotion240: Turn the LED backlight on or off for 120Hz drive display.

120Hz High/120Hz Low: For obtaining a clearer image.

Off: Normal image.

LC-70LE847U/LC-60LE847U

240Hz: Turn the LED backlight on or off for 240Hz drive display.

AquoMotion240: Turn the LED backlight on or off for 120Hz drive display.

120Hz High/120Hz Low: For obtaining a clearer image.

Off: Normal image.

LC-70LE745U/LC-60LE745U

120Hz High/120Hz Low: For obtaining a clearer image.

Off: Normal image.

"Motion Enhancement" may cause image noise. If this occurs, turn the function "Off".

When AV MODE is set to "GAME" or "PC", or PC format is being input, "Motion Enhancement" is not available.

Quad Pixel Plus 2

(For LC-80LE844U/LC-70LE847U/LC-60LE847U)

Smoothes diagonal lines by detailed dot control.

Advanced: Produces smoother diagonal lines by jaggy removal process.

Standard: Produces smooth diagonal lines.

Off: No adjustment.

Active Contrast

Automatically adjusts the image contrast according to the scene.

On: Automatically adjusts the image contrast.

Off: No adjustment.

Gamma Adjustment

Adjusts the differences of picture tones between bright parts and dark parts. The adjustment range of the gamma can be set to a maximum of +2 and a minimum of –2 by pressing c or d.

Black Level

Adjusts on-screen black level to your preferred level.

High: The black level gets brighter.

Low: The black level gets darker.

"Black Level" is available for input signal from Composite Video, Component 480i and analog broadcasts (air and cable).

Film Mode (3:2 pull-down)

Automatically detects a fi lm-based source (originally encoded at 24 frames/second), analyzes it then recreates each still fi lm frame for high-defi nition picture quality.

Advanced: Adjust effect to reduce judder from fi lm contents. Select a desired level of judder reduction from 0 to +10.

Standard: Detects, analyzes, converts fi lm source.

Off: Normal viewing mode.

"Film Mode" does not function depending on input signal type.

"Film Mode" does not function when you set AV MODE to "GAME" or "PC".

"Standard" does not function when channel display shows an input signal resolution of 480p, 720p, or 1080p.

Digital Noise Reduction

Produces a clearer video image.

Auto: Automatically adjusts the level of noise reduction.

High/Middle/Low: Select a desired level for viewing a clearer video image.

Off: No adjustment.

"Digital Noise Reduction" is not available when you set AV MODE to "PC" or PC format is being input.

When AV MODE is set to "GAME", "Auto" is not available.

Monochrome

For viewing a video in monochrome.

On: For viewing in monochrome.

Off: Normal color.
