LG Electronics TL-AT130M Servo Circuit, Video is unstable in PB mode, Drum motor stops

Page 14

SECTION3 ELECTRICAL

ELECTRICAL TROUBLESHOOTING GUIDE

2.SERVO CIRCUIT

(1)Video is unstable in PB mode

In PB mode

Does noise level on the screen

change periodically?

YES

Does CTL pulse appear at

NO

IC501 Pin 76?

YES

NO

Does CTL pulse move on tracking?

YES

Does Video Envelope wave form NO appear at IC501 pin 86?

YES

Replace IC501.

Is adjusting height of CTL

head accurate?

Replace IC501.

Check the Pre-Amp circuit

NO

Readjust the height

of CTL fead.

(2) Drum motor stops

When the drum moter stop

NO

Is there 12V at PMC01 Pin8?

YES

Check Power circuit

Is there 2.8V at PMC01 Pin12?

YES

Check the Ass’s between

connector(PMC01) and Drum motor

NO

Does Drum PWM pulse

NO



appear at IC501 Pin34?



YESYES

Aren’t pattern or componets between

IC501 Pin34 and PMC01 Pin12 short?

Does DFG pulse appear at

NO

IC501 Pin65?

YES

Does DFG pulse appear at

PMC01 Pin3?

NO

Check the Ass’y between

junction PCB and Drum motor

Aren’t pattern or componets between

IC501 Pin34 and PMC12 Pin1 short?

Does Drum PWM pulse appear

NO

Replace IC501

at IC501 Pin34?





























YES

Aren’t pattern or componets between

IC501 Pin34 and PMC01 Pin12 short?

3-4
