Topfield TF4000Fe, TF5000Fe user manual Subtitle, Teletext, Sound Track, Multifeed

Page 38

FUNCTION GUIDE

Subtitle

You can choose a language of subtitle using



button on the RCU.







If the broadcaster provides subtitles, you can see

symbol in the Information Box.

Teletext

If the broadcaster supports teletext, you can see symbol in the Information Box. There are VBI insertion mode and software emulation mode in teletext. In the VBI insertion mode, which is always on, you can watch the teletext with your TV using the RCU of your TV. To watch teletext with VBI insertion, your TV must support teletext.

In the software emulation mode, you can watch the teletext even though your TV does not support teletext. You can watch the teletext using the RCU of STB.

Press Teletext ( ) button to watch the teletext with software emulation mode.

Press button once more or EXIT ( ) button to escape from teletext.

Sound Track

You can choose a language of soundtrack by

pressing

button when a broadcaster

supports various languages of soundtrack. Also, it is possible to choose a mode among

Stereo, Mono, Left and Right using

,

buttons.

button is used for multifeed

function,

too. If the multifeed is available in

current service,

Multifeed Track will be displayed first. You can change the display to Sound Track

selection menu by pressing



button once more.



Multifeed

If multifeed is available in the service, Multifeed Icon ( ) will appear at the right side of the Information box. If available, the Multifeed Track and Sound Track are toggled by button. It is possible to choose one of the multifeed services.

38

Image 38
Contents User’s Manual Table of Contents Do not Expose this Appliance to Rain or Moisture Earthing The antenna cable must be earthed Contents IntroductionFeatures FRONT/ Rear Panels 1FRONT PanelLNB Remote Control Unitrcu Button Red Connection to TV, VCR and Hi-Fi Installation ConnectionConnection to the TV using the RF cable Connection to the TV with the Scart CableConnection to the other Satellite Receiver Getting StartedMenu Operations Mode System SettingLocal Time Setting Local TimeVCR Timer Setting Time OffsetParental Control EveryWeekend , Weekly , and Every Weekday CensorshipChange PIN Code Access ControlLanguage Setting Audio Language Menu LanguageSubtitle Language TV Type Output SettingSound Mode Video OutputInfo Box Position OSD TransparencyInfo Box Display Time Move Organizing ServicesBrowse SkipOrganizing Favorites To perform a new service search SortFav List , Fav Services and TV or Radio Services List DeleteInstallation Menu Operations Symbol Rate Service Search Satellite NameSearch Mode FrequencyFTA/Scrambled Video PIDAudio PID Start SearchMotorized DiSEqC1.2 DiSEqC Command ModeMotorized DiSEqC Motor Control Followings are available only at the Installer modeUsals Setting My Longitude Motorized DiSEqC1.3Satellite Angle My LatitudeSAT/TP Edit Satellite Name SAT Name EditDelete TP Factory SettingAdd New TP Add SatelliteSame specification System RecoveryRecover StoreFirmware Upgrade Astra HotbirdCalendar InformationIRD Status Game ExBlock Bomb Hexa Pac ManInformation Box Service ListFunction Guide EPG Electronic Program Guide CASSound Track SubtitleTeletext MultifeedSoftware Upgrade and PC Interface Software UpgradeMenu MAP GMTPID Menu MAP Specifications Tuner & Channel DecoderPhysical Specification 340mm Model Rev.2

TF4000Fe, TF5000Fe specifications

The Topfield TF5000Fe and TF4000Fe are two prominent models in the world of digital television receivers, renowned for their reliability and advanced functionalities. Both devices have carved a niche for themselves in the competitive market, appealing to users who seek a balance of performance and affordability.

One of the most significant features of the Topfield TF5000Fe and TF4000Fe is their ability to receive digital terrestrial television (DTT) signals, ensuring high-definition picture and sound quality. This functionality allows users to access a wide range of channels without the need for a satellite dish or cable subscription. The devices support DVB-T standards, making them compatible with most broadcasting systems worldwide.

The TF5000Fe, in particular, stands out with its robust recording capabilities. Equipped with a built-in hard drive, it allows users to record their favorite shows, providing the convenience of time-shifting. The Timeshift feature enables viewers to pause live TV and resume watching later, a valuable tool for those who often find themselves distracted during programming. This model is also compatible with USB devices, offering the flexibility to record directly onto removable storage.

The TF4000Fe, while slightly simpler, does not fall short in performance. It features a more compact design, ideal for those with limited entertainment space. Both models incorporate advanced EPG (Electronic Program Guide) systems, allowing viewers to navigate through scheduled broadcasts and set reminders for upcoming shows easily.

User-friendliness is another hallmark of Topfield products. Both receivers come with intuitive remote controls, and their on-screen menus are designed to enable quick navigation. The installation process is straightforward, often completed in mere minutes, making them accessible for users of all technical levels.

In terms of connectivity, both the TF5000Fe and TF4000Fe provide multiple options. They include HDMI outputs for high-definition resolution as well as standard AV outputs for older televisions. This versatility ensures that they can integrate seamlessly into any home entertainment system.

Another notable characteristic is their support for various video formats, allowing users to enjoy a range of media content. This flexibility extends to the devices’ capability to play back multimedia files, making them a multifaceted addition to any entertainment setup.

In summary, the Topfield TF5000Fe and TF4000Fe embody the perfect blend of advanced technology and ease-of-use, making them excellent choices for anyone looking to enhance their television viewing experience. Whether it’s the expansive recording features of the TF5000Fe or the space-saving design of the TF4000Fe, both receivers deliver outstanding performance to meet the demands of modern viewers.
