HYUNDAI LCD TV HQL260WR/320WR

How to Set the Desired Picture

Users can manually adjust the picture in their own ways.

MENU

1

2

3

INPUT

Press Menu button.	Picture
Menu items appear on the screen.	Sound
Menu items appear on the screen.	Clock
	Clock
	Install
	Language
	Advanced
Press Left, Right or OK button to select
Press Left, Right or OK button to select	MENU : Previous			: Select
“Picture”.	INPUT : Exit		OK : Select
“Picture”.	: Position
	: Position

Press Up and Down buttons to Choose	Picture

	Mode				Custom
one of the items listed.	Mode				Custom
one of the items listed.	Contrast						61
	Brightness						70
	Sharpness						14
	Colour						50
Press Left and Right buttons to adjust.	Tint						0

	MENU : Previous				: Adjust
	INPUT : Exit
	INPUT : Exit
	: Position

Press MENU button after the setting is done, and Menu goes to the previous menu. If the INPUT button is pressed, the menu disappears.

CONTRAST : Adjust the brightness and darkness of object and background.

BRIGHTNESS : Adjust the brightness of the entire picture.

SHARPNESS : Adjust clarity of outline of objects. This is not applied to DTV, PC mode.

COLOR : Adjust colors into deeper or lighter colors.

TINT(HUE) : Adjust colors naturally.

This is not applied to PC, TV mode.

PICTURE SETUP

If you adjust the Picture in step 3 while it is in Standard, Sports, Natural or Mild mode, the mode will change to Custom mode.

*Adjustments menu may be different according to the input source.

36
