Toshiba 42/51WH46 owner manual Specifications and accessories

Page 24

Specifications and accessories

Broadcast systems/channels
PAL-I	UHF UK21-UK69
PAL-B/G	UHF	E21-E69
	VHF	E2-E12, S1-S41
SECAM-L	UHF	F21-F69
	VHF	F1-F10, B-Q
SECAM-D/K	UHF	R21-R69
	VHF	R1-R12

Video Input		PAL, SECAM, NTSC 3.58/4.43
External connections
EXT1	Input		21-pin SCART	RGB, A/V
EXT2	Input		21-pin SCART	RGB, A/V
EXT3	Input/Output		21-pin SCART	A/V, S-video
				Selectable output
EXT4	Input (side/front)		4-pin	S-video
			Phono jack	Video
			Phono jacks	Audio L + R
Fixed/Variable Output			Phono jacks	Audio L + R
Output to Active Super Woofer			Phono socket

42/51WH46

2356 6300

Programme Positions			100
Stereo			Nicam
			2 carrier system
Visible Screen Size			42WH	106cm
(approx.)			51WH	129cm
Display			16:9
Sound output (at 10% distortion)			Main	14W + 14W
Power consumption			42WH	160W
as specified in EN60107-1 : 1997			51WH	160W
Standby			42WH	<2.5W
			51WH	<2.5W
Dimensions	42WH	116cm (H) 101cm (W) 42cm (D)
(approx.)	51WH	128cm (H) 121cm (W) 57cm (D)
Weight (approx.)			42WH	52kg
			51WH	65kg
Headphone socket			3.5mm stereo
Accessories			Remote control
			2 batteries
			(UM-4, AAA, IEC R03 1.5V)

Printed on recycled paper. 100% Chlorine free.

© Toshiba Information Systems (U.K.) Limited

All rights reserved.

Reproduction in whole or part without written permission is strictly prohibited.

Toshiba Information Systems (U.K.) Limited

Consumer Products Division,

European Service Centre,

Admiralty Way, Camberley,

Surrey, GU15 3DT, UK

Specification is subject to change without notice.

Originated by Kensa Creative Solutions, Saltash, Cornwall.

Image 24
