6E_body17p.fm Page 31 Wednesday, December 19, 2001 4:50 PM

Appendix

Display Modes

If the signal from the system equals to the standard signal mode, the screen is adjusted automatically. If the signal from the system doesn’t equal to the standard signal mode, adjust the mode with refering to the Videocard user guide because the screen might not display or only the power LED might be on. For the display modes listed below, the screen image has been optimized during manufacture.

Table 7. Preset timing modes

Mode

Resolution

Horizontal

Vertical

Pixel Clock

Sync Polarity

Frequency

Frequency

Frequency

(H/V)





(kHz)

(Hz)

(MHz)





















720 x 400

31.469

70.087

28.322

–/+













VGA

640 x 480

31.469

59.940

25.175

–/–











640 x 480

37.500

75.000

31.500

–/–

















640 x 480

43.269

85.008

36.000

–/–













SVGA

800 x 600

46.875

75.000

49.500

+/+











800 x 600

53.674

85.061

56.250

+/+

















1024 x 768

48.363

60.004

65.000

–/–













XGA

1024 x 768

60.023

75.029

78.750

+/+















1024 x 768

68.677

84.997

94.500

+/+













SXGA

1280 x 1024

63.981

60.020

108.000

+,–/+,–











(LW-17E24C only)

1280 x 1024

79.976

75.025

135.000

+/+















English 31
