Adjustment Method (Color Cameras)

Switch no.

Function

Off

On

1

GAMMA

Off (0.45)

On (1.0)









2

AE (Automatic

Off

On (see Manually Setting



Exposure)



Shutter Speed (Color







Cameras))









3

FLON (Flicker

Off

On



Less)













4

BLC (Backlight

Off

On (Center window)



Compensation)













5

IRIS Control

Electronic

Auto IRIS





IRIS











6

Not used

Not used

Not used









7

AGC

4 dB

26 dB









White Balance Adjustment Method (Color Cameras)

Symbol

SWB8

SWB9

SW10



AWB1

AWB2

AWB3









AWB

Off

Off

Off









ATW

Off

On

Off









Push lock

Off

On

On *









Indoor (3200° K)

On

Off

On









Outdoor (6500° K)

On

On

On

*To manually set Push lock feature: place a white background in front of camera and press “Push lock” switch.
