Honeywell HD28D4HR9X Cable Guidelines, Coaxial video cable maximum length feet/meters Cable type

Page 19

Cable Guidelines

Power supply cable maximum length (feet/meters)

Cameras with AC/DC power supplies



Wire gauge







Power supply

24 AWG

22 AWG

18 AWG

16 AWG

15 VDC

45/14

73/22

185/56

295/90

24 VAC

408/125

660/201

1674/510

2664/812

Note Calculations are based on an unregulated linear power supply which would be the worst case. Using a regulated or switching power supply can increase the cable distance. Honeywell recommends using a CSA Certified/UL listed Class 2 power supply to ensure compliance with electrical safety standards.

Coaxial video cable maximum length (feet/meters)

Cable type

RG-59

RG-6

RG-11

Wire gauge

23 AWG*

18 AWG*

14 AWG*

Maximum length

750/229

1500/457

2000/610

* Copper clad steel core, 95% braided shield

Rev 1.01

14

Document 900.0275





10/05

Image 19
