MECHANICAL CHASSIS ASSEMBLY (3)

Ref.No.	Part No.	Part Name & DescriptionPcs		Remarks
1	VXA8012	CASSETTE COMPARTMAENT	1 (M)
2	VXA6362	TOP PLATE ASS'Y	1
3	VMC1290	CASSETTE PRESSURE SPRING	1
4	VML3100	ADAPTOR STOPPER	1
5	VMX0967	CUT WASHER	3
6	VMB2961	SPRING	2
7	VXA6050	SIDE PLATE (R)(1) ASS'Y	1
8	VDG0387	DUMPER	1
9	VXA6365	BACK PLATE ASS'Y	1
10	VXA6367	SIDE PLATE (L)(1) ASS'Y	1
11	VXL2896	RATCHET LOCK LEVER ASS'Y	1
12	VXL2740	RATCHET ARM	1
13	VMB2981	RATCHET SPRING	1
14	VMB3025	SPRING	1
15	VXA5632C	T RECEIVER ANGLE ASS'Y	1
16	VXA5631C	S RECEIVER ANGLE ASS'Y	1
19	VDP1880	MAIN ARM ROLLER	2
20	XWGV4Y6G	WASHER	2
21	VMA0T40	H-BUFF ANGLE	1
22	VMA0T43	SUB CHASSIS	1
23	VXA6368	CASSETTE HOLDER ASS'Y	1
24	VMA0T33	RF EQ ANGLE (T)	2
25	VSC5732	SHIELD ANGLE	1
101	XYN2+C8FJ	SCREW	1
102	XUC2FP	E-RING	2
103	XWGV3Y5G	WASHER	2
104	XQN14+A3FJ	SCREW	4
105	XWGV2Y4G	WASHER	2
106	XQN2+CF3FJ	SCREW	8
107	XYN3+C5	SCREW	3
108	XQN2+A2FJ	SCREW	4
109	XYN26+J6FJ	SCREW	4
110	XYN3+C4FJ	SCREW	2

Ref.No.

Part No.

Part Name & DescriptionPcs

Remarks

E14

VEP82248L

SERVO P.C.BOARD

1
