Panasonic NV-GS35GN, NV-GS25GN Fitting the lens cap, Grip belt, Using the LCD monitor

Page 6

Before using

(38)Shoulder strap fixture

1

3

2

Put the strap through the fixture 1 and through the stopper 2 so it will not come off. Extend part 3 by at least 2 cm.

Fit the other end of the belt similarly.

Fitting the lens cap

Fit the lens cap to protect the surface of the lens.

1The lens cap and lens cap cord comes preattached to the grip belt.

Pass the end of the lens cap cord through the attached eye on the lens cap. Then pass the lens cap through the loop made by itself and pull tight.

When not using the Lens Cap, pull the Lens Cap Cord in the direction of the arrow. 1 When you are not recording, be sure to cover the Lens with the Lens Cap for protection. 2

1

2



When you remove the lens cap, press the knobs firmly.

6

The grip belt

Adjust the belt length so it fits your hand.

1Adjust the belt length.

2

1 3

1Flip the belt.

2Adjust the length.

3 Fix the belt.

Using the LCD monitor

You can record the image while viewing it on the LCD monitor opened.

1Put a finger on the LCD monitor open part and pull the LCD monitor out in the direction of the arrow.

The viewfinder will go off.

It can open up to 90o.

2Adjust the angle of the LCD monitor as you prefer.

1 180o

2 90o

It can rotate up to 180o 1 towards the lens or 90o 2 towards the viewfinder.

The brightness and colour level of the LCD monitor can be adjusted from the menu.

If it is forcibly opened or rotated, the camera may be damaged or fail.

Check that the card slot cover is closed. When the LCD monitor is rotated by 180o

towards the lens (when recording yourself), the LCD monitor and the viewfinder will be simultaneously activated.

LSQT0893

Image 6
