User Manual DataCourier

InstallationInstallation ofof mobileobile printerprinter

Open your DataCourier and proceed as follows:

1)Take four Velcro pads and press two corresponding pairs together. (Fig. 1 showing a pair being pressed together)

2)Now you have two Velcro pairs with protective films on each side. Remove the protective film on one side of each pair to reveal the adhesive tape beneath and press them to one corner each of your printer. (Fig. 2; the white tape must still be removed, the Velcro pads can also be placed in the center of the printer)

CAUTION!

Before you mount the printer, please check the intended position on the flap since incorrect mounting can cause problems during printer operation.

3)The easiest way to mount the printer is on the open front flap. Mount the printer with its back

side (battery side) on the closed cable box in the center and press against the lid. The further back you mount the printer the better for balance, since then the DataCourier does not tip over so easily.

For more information please contact us at info@dicota.com.

Fig. 1

Fig. 2

8
