Sears 831.283120 user manual HOW to Operate the Exercise Cycle, HOW to Adjust the Seat Post

Page 9

HOW TO OPERATE THE EXERCISE CYCLE

HOW TO ADJUST THE SEAT POST



For effective exer-





cise, the seat





should be at the



Seat

proper height. As







you pedal, there





should be a slight

Seat

Knob

bend in your knees



when the pedals

Post



are in the lowest





position. To adjust





the height of the





seat, first turn the





indicated knob counterclockwise two or three turns to loosen it (if the knob is not loosened enough, it may scratch the seat post). Next, pull the knob, slide the seat post to the desired height, and then release the knob. Move the seat post up and down slightly until the pin on the knob snaps into one of the holes in the seat post. Then, turn the knob clockwise until it is tight.

HOW TO ADJUST THE SEAT

The seat can be

HOW TO ADJUST THE UPRIGHT



The upright can be



adjusted to the



height that is the



most comfortable for

Upright

you. To adjust the



upright, first turn the



indicated knob



counterclockwise



two or three turns to



loosen it (if the knob

Knob

is not loosened



enough, it may



scratch the upright).



Next, pull the knob,



slide the upright to



the desired height,



and then release



the knob. Move the upright up and down slightly until the pin on the knob snaps into one of the holes in the upright. Then, turn the knob clockwise until it is tight.

HOW TO ADJUST THE PEDAL STRAPS

adjusted to the





position that is the





most comfortable

Seat



for you. Before







adjusting the seat,

Seat

Knob

dismount the



Bracket



exercise cycle; do







not adjust the





seat while you are





sitting on it. To





adjust the seat, first





turn the indicated knob counterclockwise two or three turns to loosen it (if the knob is not loosened enough, it may scratch the seat bracket). Next, pull the knob, slide the seat to the desired position, and then release the knob. Move the seat bracket forward and back- ward slightly until the pin on the knob snaps into one of the holes in the seat bracket. Then, turn the knob clockwise until it is tight.

To adjust the pedal straps, first pull the ends of the straps off the tabs on the pedals. Adjust the straps to the desired position, and press the ends of the straps back onto the tabs.

Pedal

Strap

Tab

9
