ASSEMBLY FOR FRONT AND REAR STABILIZER
Step 1:
Attach the front stabilizer (2) to the main frame (1) using 2 allen bolts (48) and 2 flat washers (61). From underneath the front stabilizer (2), you will use 2 flat washers (61) and 2 nuts (80) to secure it.
Step 2:
Assemble the rear stabilizer (3) to the main frame (1) using 2 allen bolts (48) and 2 flat washers (61). From underneath the rear stabilizer (3) you will use 2 flat washers (61) and 2 nuts (80) to secure it.
1
3
61
61
48
USE | USE |
TOOL | TOOL |
| 6 mm |
2
61
80
48
61
|
| 80 | Note: |
|
|
| The front and the rear stabilizers are very |
|
|
| similar, but the front stabilizer has transport |
|
|
| wheels. |
6 | Important Information | Unpack all parts and place them in a clear area. Be sure to remove all packing material. | |
| Assembly | ||
