Page 12

CLASSIC UPRIGHT BIKE	CLSC-0XXX-01
Idler Bracket Assembly	S/N CLU100000 and up

Idler Bracket Assembly AK63-00021-0000

Idler Bracket

0K63-01050-0000

Lock Nut

0017-00103-0218

Idler w/Bearing

AK63-00008-0000

12

Image 12
