Installation | Preparing the load |
|
|
Installation requirements
1 |
SUPPLY CORD |
AIR INLET |
VENTS |
AIR OUTLETS |
IN BASE |
IMPORTANT: This dryer must be installed such that the air inlets and outlets are not restricted (fig. 1).
There should be a gap of at least 12mm
(0.5 inches) between the sides rear and base of the machine and the surrounding walls, cabinets and floor.
To ensure adequate ventilation the space between the bottom of the machine and the floor must not be obstructed.
NEVER install the dryer up against curtains.
Prevent items from falling or collecting behind and beneath the dryer as these may obstruct the air inlets and outlets.
Preparing the load
Before using the dryer for the first time wipe the inside of the drum and door with a damp cloth.
Make sure that the laundry you are going to dry is suitable for drying in a tumble dryer, as shown by the care symbols on each item.
Clothes preparation
Check that all fastenings are closed and that pockets are empty. Turn the articles inside out. Place clothes loosely in the drum to make sure that they don’t get tangled.
Warning:
Do not overload the drum, large items when wet can exceed the maximum admissible clothes load (for example: sleeping bags, duvets).
Maximum drying weight
●Cottons Max. 7 kg
●Synthetics Max. 3 kg
Sort the load as follows:
A) By care symbols
On the collar or inside seam:
Suitable for tumble drying.
Tumble drying at high temperature.
Tumble drying at low temperature only.
Do not tumble dry.
B)By amount and thickness Whenever the load is bigger than the dryer capacity, separate clothes according to thickness (e.g. towels from thin underwear).
