Hitachi AJ-S70KXP How to Use Liquid Detergent, Bleach, Fabric Softener, 洗衣粉、漂白劑、柔軟劑的使用方法

Page 21

How to Use Liquid Detergent, Bleach, Fabric Softener

洗衣粉、漂白劑、柔軟劑的使用方法

Start the washing machine with water in the washing basket, and the infiltration washing can't perform then. Please put the detergent in the washing • spinning basket.

在洗衣槽有水時￿動洗衣機，不能進行滲透清洗。請將洗衣粉放入洗衣‧脫水槽內。

Powder synthetic detergent 粉末合成洗衣粉

■Put the detergent in the detergent dispenser

將洗衣粉放入洗衣粉加入盤內

Notes 備注

約 50 °

1Open the detergent dispenser

打開洗衣粉加入盤

2Pour in the detergent 倒入洗衣粉

Close the deter-

Detergent

3gent dispenser

dispenser

關閉洗衣粉加入盤

洗衣粉加入盤



Lint filter



棉絮過濾網

•When water is adhering to the detergent dispenser, please wipe it first.

洗衣粉加入盤有水滴時，請擦乾水滴後注入洗衣粉。

•When the detergent adheres to the dispenser, it remains even the dispenser is closed. If the detergent still adheres to the dispenser after 2 or 3 times of repetitive

open and close, please remove the dispenser for cleaning up. ( 43)

洗衣粉黏附在盤上時，即使關閉，洗衣粉也會殘留在加入盤內。反復開關2、3次

後仍然附在加入盤上時，請拆下加入盤進行清洗。 ( 43)

•Please pay attention to keep the detergent away from the injection opening of fabric softener, so as to avoid malfunction.

請注意避免將洗衣粉注入柔軟劑注入口內，以免引致故障。

•Some types of detergent may be hard to dissolve.

In this case, please inject the detergent into the washing basket directly after it sufficiently dissolves.

有些種類的洗衣粉可能較難溶解。

此時，待洗衣粉充分溶解後請直接將其注入洗衣槽內。

•In the case of bulky laundry, sometimes it may be hard to open the detergent dispenser.

In this case, please move the laundry to the opposite side of injection opening, then open the dispenser.

洗衣量太多時，有可能難以打開洗衣粉加入盤。

此時，請將衣物撥向注入口的對面一則，再打開加入盤。

•Only after closing the detergent dispenser can the operation begin. The laundry may be damaged under the operation with the dispenser open.

請務必關閉洗衣粉加入盤後才可進行運轉。在加入盤開￿狀態下運轉，很可能會損 傷衣物。

•The detergent dispenser can be opened as much as about 50 degrees. Any action to open it by force may cause damage.

洗衣粉加入盤只能打開約 50 °的角度。強行打開可能會造成損壞。

■ How to install the detergent dispenser

■ How to uninstall the detergent dispenser

洗衣粉加入盤的安裝方法



洗衣粉加入盤的拆卸方法

Insert the pin into the pin hole at the injection opening.

1 Bend the detergent dispenser.

將洗衣粉加入盤的銷釘分別插入注入口兩端的銷釘孔內。

彎折洗衣粉加入盤。





2 Disassemble the pin off the pin hole.





將銷釘從銷釘孔中卸下來。

Injection opening





注入口









Pin





銷釘





Pin hole





銷釘孔



Pin hole



Pin

銷釘孔







銷釘





Detergent dispenser





洗衣粉加入盤





21
