Solid State Logic X-Rack E Series LF EQ Maximum Gain, Output Balance, ‘Balance’ Adaptor

Page 8

X-Rack Owner’s Manual

K.4.2

K.4.3



4.

Switch BLK in and re-adjust LMF Frequency for maximum level.



5.

Adjust VR16 for +18dBu ±0.25dB.



6.

Reset LMF Gain to its centre indent position and release the BLK switch.

LF EQ – Maximum Gain



Re-check the audio level meter for 0dBu.

1.

Ensure that the BLK switch is released.

Adjustment:



2.

Set LF Gain to maximum and select LF BELL. Set the audio oscillator for





80Hz and adjust LF Frequency to find the maximum level on the audio



3.

level meter.



Adjust VR17 for +15dBu ±0.25dB.



4.

Switch BLK in and re-adjust LF Frequency for maximum level.



5.

Adjust VR18 for +18dBu ±0.25dB.



6.

Reset LF Gain to its centre indent position, release the BLK switch and de-

Output Balance



select LF BELL. Re-check the audio level meter for 0dBu.



Calibrated audio oscillator, audio level meter and a ‘balance’ adaptor (see

Equipment Required:



Test Signal:



below).



1kHz sine wave at +24dBu.

Input and Output:



Oscillator to the Input of the channel being tested, Output to the level

Unit Setup:



meter via the ‘balance’ adaptor.



Ensure that all front panel switches are off and all controls are set fully

Adjustment:



anti-clockwise.



Connect the test equipment to the each channel in turn and adjust VR19





(BAL) for minimum level (< 55dBr).

‘Balance’ Adaptor



0V

1







3





For the output balance adjustment, a ‘balance’













adaptor such as that illustrated here will be







5K01**

1









required. This adaptor consists of a pair of

From unit

+

2







2



To measuring

2









close tolerance resistors in an in-line cable and

under test



3



**

1



+





5K01





is used to sum together a balanced output in











1

0V

equipment



























order to correctly adjust the level balance of the

















measured output; perfect balance should result

Note 1.

Resistor tolerance should ideally be 0.01%



in complete signal cancellation.





2.

Absolute level measured will depend upon the input







impedence of the measuring equipment.
