K.5 Connector Details

Audio Input





Location:

Rear Panel

Conn’ Type:

XLR Female

Pin

Description

1



Chassis

2

3

Audio +ve



Audio –ve

X-Rack E Series EQ Module

Audio Output





Location:

Rear Panel

Conn’ Type:

XLR Male

Pin

Description

1



Chassis



3

2

Audio +ve



Audio –ve

K.6 Physical Specification

including front panel knobs, excluding connectors

Depth:

200mm / 7.9 inches

Height:

275mm / 10.9 inches

including front panel knobs and connectors

171mm / 6.75 inches

front/rear panels

Width:

35mm / 1.4 inches

Weight:

49mm / 1.9 inches

overall width (front and rear panels are offset)

260g / 9.5 ounces



Boxed size:

190mm x 290mm x 70mm / 7.5" x 11.5" x 2.5"

Boxed weight:

460g / 16.5 ounces



* All values are approximate



K.7 Environmental Specification

As per X-Rack – see page 19.

Page K-7
