DMX-512 Values Continued

CHANNEL	DESCRIPTION	VALUES
7) GOBO WHEEL	BIGSPOT	0-7
	TUNNEL	7-15
	TRI-TUNNEL	16-23
	SUN FLOWER	24-31
	DUAL DOTTED LINE	32-39
	SINGLE DOTTED LINE	40-47
	TRIANGLE	48-55
	SWIRL	56-63
	MULTI-STAR	64-71
	SEGMENT TUNNEL	72-79
	STAR	80-87
	SMALL SPOT	88-95
	SEGMENT SQUARES	96-103
	TWISTER	104-111
	SPLIT FOUR	112-119
	BARS	120-127
	SPLASH	128-135
	ASTERISK	136-143
	MULTI-SMALL DOT	144-151
	EUROSTARS	152-159
	BUBBLES	160-175

CHANNEL	DESCRIPTION	VALUES
8) SHUTTER / DIMMER
	BLACKOUT	0-15
	STROBE (FAST > SLOW)	16-127
	OPEN SHUTTER	128-255

© American DJ® Los Angeles, CA 90058 USA The MAX™ User Instructions page 5
