CS-MKE12NB4U × | Panasonic CU-4KE31NBU, CU-4KE24NBU, CU-3KE19NBU

Outdoor Unit	: CU-3KE19NBU
Indoor Unit	: CS-MKE12NB4U × 3
Power Supply : 230V Single Phase 60Hz
	< Cooling Capacity >

	RATING CAPACITY:			17,400 BTU/h			AIR FLOW RATE:			706 CFM
	INDOOR						OUTDOOR
	ENT. TEMP. o F ( o C)					AMBIENT TEMP. o F ( o C)
	WB		DB		65	75	85	95		105	115
					(18.3)	(23.9)	(29.4)	(35.0)		(40.6)	(46.1)
				TC	17,460	16,880	16,260	15,760		15,020	14,220
		72	(22.2)	SHC	15,450	15,180	14,900	14,630		14,350	13,940
	59	76	(24.4)	SHC	17,460	16,880	16,260	15,760		15,020	14,220
	(15.0)	80	(26.7)	SHC	17,460	16,880	16,260	15,760		15,020	14,220
		84	(28.9)	SHC	17,460	16,880	16,260	15,760		15,020	14,220
		88	(31.1)	SHC	17,460	16,880	16,260	15,760		15,020	14,220
				TC	18,290	17,700	17,060	16,570		15,810	14,980
		72	(22.2)	SHC	12,570	12,300	12,020	11,890		11,610	11,200
	63	76	(24.4)	SHC	15,180	14,900	14,630	14,490		14,080	13,810
	(17.2)	80	(26.7)	SHC	17,920	17,650	17,060	16,570		15,810	14,980
		84	(28.9)	SHC	18,290	17,700	17,060	16,570		15,810	14,980
		88	(31.1)	SHC	18,290	17,700	17,060	16,570		15,810	14,980
				TC	19,120	18,520	17,870	#	17,400	16,620	15,760
		72	(22.2)	SHC	9,690	9,420	9,140	9,000		8,730	8,460
	67	76	(24.4)	SHC	12,300	12,020	11,750	11,610		11,340	11,060
	(19.4)	80	(26.7)	SHC	15,040	14,770	14,490	14,350		14,080	13,670
		84	(28.9)	SHC	17,650	17,370	17,100	16,960		16,620	15,760
		88	(31.1)	SHC	19,120	18,520	17,870	17,400		16,620	15,760
				TC	19,950	19,350	18,690	18,240		17,440	16,560
		72	(22.2)	SHC	6,540	6,400	6,120	5,990		5,710	5,440
	71	76	(24.4)	SHC	9,140	9,000	8,730	8,590		8,320	8,040
	(21.7)	80	(26.7)	SHC	11,890	11,750	11,470	11,340		11,060	10,790
		84	(28.9)	SHC	14,490	14,350	14,080	13,940		13,670	13,390
		88	(31.1)	SHC	17,100	16,960	16,690	16,550		16,270	16,000

				TC	20,670	20,070	19,400	18,990		18,180	17,290
	75	76	(24.4)	SHC	6,260	5,990	5,850	5,710		5,440	5,160
	(23.9)	80	(26.7)	SHC	9,000	8,730	8,590	8,460		8,180	7,910
		84	(28.9)	SHC	11,610	11,340	11,200	11,060		10,790	10,510
		88	(31.1)	SHC	14,220	13,940	13,810	13,670		13,390	13,120

TC : Total Cooling Capacity (BTU/h) SHC : Sensible Heat Capacity (BTU/h)

NOTE

1.Rating conditions (#) : Indoor Unit Entering Air Temp. 80 °F (26.7 °C) DB / 67 °F (19.4 °C) WB

:Outdoor Ambient Temp. 95 °F (35 °C) DB

2.Above data does not take Freeze Prevention Protection during cooling operation into account. For this reason, the value may vary from the actual cooling characteristics.

3.Above data represents the value when the operation frequency of a compressor is fixed.

CU-3KE19NBU, CU-4KE24NBU, CU-4KE31NBU specifications

The Panasonic CU-4KE24NBU, CU-4KE31NBU, and CU-3KE19NBU are high-efficiency air conditioning units that represent Panasonic's commitment to innovative climate control solutions. These models integrate advanced technologies to deliver superior performance, energy savings, and user comfort, making them ideal for both residential and commercial applications.

The CU-4KE24NBU, a part of the ECOi series, is designed for medium-sized spaces. It boasts an impressive cooling capacity, ensuring optimal temperature regulation. Its inverter technology adjusts the compressor speed according to the needs of the environment, resulting in reduced energy consumption and consistent comfort levels. The unit operates quietly, making it suitable for bedrooms, offices, or other noise-sensitive environments. Additionally, it features a robust air filtration system that improves indoor air quality by removing dust and allergens.

The CU-4KE31NBU offers a slightly higher capacity, making it perfect for larger areas. Like its counterpart, it utilizes inverter technology, which not only enhances energy efficiency but also minimizes wear and tear on the components, leading to a longer lifespan. Its multi-split capability allows for the connection of multiple indoor units to a single outdoor unit, providing flexibility in installation. The CU-4KE31NBU also integrates smart technology that allows users to control the system remotely via smartphones, giving them greater convenience and control over their environment.

For applications requiring a more compact option, the CU-3KE19NBU is an excellent choice. This model balances size and power, offering a competitive cooling capacity that can easily service small to medium-sized rooms. The unit is designed for easy installation and maintenance, featuring a lightweight construction that simplifies handling by technicians. The efficient inverter technology ensures that users benefit from lower energy bills while maintaining a consistent indoor climate.

All three models are equipped with Panasonic’s advanced refrigerants, which contribute to their eco-friendly performance. These refrigerants help reduce greenhouse gas emissions while maintaining high efficiency. Moreover, the units come with built-in diagnostic capabilities, allowing for quick detection of any issues, thus ensuring that the systems operate at peak efficiency throughout their lifespan.

In summary, the Panasonic CU-4KE24NBU, CU-4KE31NBU, and CU-3KE19NBU are exemplary air conditioning solutions that combine cutting-edge technology with user-friendly features, ensuring that they meet the varying needs of today's consumers while promoting energy efficiency and sustainability.
