AC Output: The circuit breaker or fuse must be rated at no more than



the rating of the input breaker in the installation and must be



approved for use on 120 Vac branch circuits. The wire used between



the Freedom HF and the AC output breaker must be of adequate size



to match the AC input circuit breaker’s rating. The wiring from each



AC output breaker to each of the loads must be adequately sized to



carry the current rating of the individual AC output breaker.



Disconnect Devices: Each system requires a method of



disconnecting the AC circuits. If the over-current protection devices



are circuit breakers, they will also serve as the disconnects. If fuses



are used, separate AC disconnect switches will be needed ahead of



the fuses. These will have to be a branch circuit rated for 120 Vac and



have an appropriate current rating.

AC Distribution

Most systems incorporate distribution centers both ahead of the Freedom

Panels

HF (the AC source panel) and between the Freedom HF and the loads (the



AC load panel). An AC source panel includes a main circuit breaker,



which serves as over-current protection and as a disconnect for the AC



shore power supply line. Additional circuit breakers serve individual



circuits, one of which serves the Freedom HF. The AC load panel can



incorporate an AC output circuit breaker and breakers for individual load



circuits.



CAUTION: Equipment damage



Do not connect the output of the Freedom HF to what is known as a “multi-wire



branch circuit”. These are four-wire circuits consisting of a ground, neutral, and



two lines that are 180 degrees out of phase with each other (from a standard 120/



240V “split phase” circuit). These circuits are commonly used in kitchens to



power “split receptacles” where the top and bottom halves of a duplex receptacle



are connected to different lines.





AC Cabling

AC cabling includes all the wires and connectors between the AC source



and the Freedom HF, as well as all cabling between the Freedom HF and



the AC output panels, circuit breakers, and loads. The type and size of the



wiring varies with the installation and load. For example, in high



vibration environments, such as marine or RV applications, wire nuts may



not be acceptable, so crimp splices would be required. In other



applications, flexible multiple-strand wire may be required. Installation



codes usually specify solid or stranded, overall size of the conductors, and



type and temperature rating of the insulation around the wire.





1–8

975-0395-01-01

This guide for use by qualified installers only
