Sears 113.24907 manual El O

Page 28

SERVICE

Now that you have purchased your Copy-Crafter, should a need ever exist for repair parts or service, simply contact any Sears Service Center and most Sears, Roebuck and Co. stores. Be sure to provide atl pertinent facts when you call or visit.

EL O,

113.249070

HOWTO ORDER

REPAIR PARTS

The model number of your Copy-Crafter will be found on a label attached to the platform channel.

WHEN ORDERING REPAIR PARTS, ALWAYS GIVE THE FOLLOWING IN FORMATION:

PART NUMBER

PART DESCRIPTION

MODEL NUMBER

NAME OF ITEM

113.249070

Copy-Crafter

All parts Iisted may be ordered from any Sears Service Center and most Sears stores. If the parts you need are not stocked loca!ly, your order will be electronically transmitted to a Sears Repair Parts Distribution Center for handling,

Sold by SEARS, ROEBUCK AND CO., Chicago, IL. 60684 U.S.A.

Part No. 70041

Form NO. SP4335-3

Printed in U,S.A. 3,/84
