Спецификации

Платформа

- форм-фактор Micro ATX







- Твердотельный конденсатор в цепи питания процессора





Процессор

- Поддерживаются процессоры для гнезда Socket FM2 с







потребляемой мощностью до 100 Вт







- Поддержка технологии AMD Cool ‘n’ QuietTM







- UMI-Link GEN2





Набор микросхем

- AMD A75 FCH (Hudson-D3)





Память

- Поддержка технологии Dual Channel DDR3 Memory Technology







- 2 x гнезда DDR3 DIMM







- Поддержите DDR3 1866/1600/1333/1066 не- ECC, безбуферная







память







- Mакс. 32 Гб







- поддержка профиля Intel® Extreme Memory Profile (XMP)1.3/1.2







- поддержка профиля AMD Memory Profile (AMP)





Гнезда

- 1 x гнезда PCI Express 2.0 x16 (PCIE1: режим x16)





расширения

- 1 x гнезда PCI Express 2.0 x1







- 1 x гнезда PCI







- Поддерживаются режимы AMD двойные видеокарты





Графика

- Видеоадаптер AMD Radeon HD 7000







- Поддержка DirectX 11, Pixel Shader 5.0







- Макс. объем разделяемой памяти 2GB







- Двойственное VGA выходное устройство: поддерживает DVI и







D-Sub порты через независимый контроллер дисплея







- Поддержка Dual-link DVI с максимальным разрешением до







2560х1600 @ 75 Гц







- Поддержка D-Sub с максимальным разрешением до 1920х1600 @







60 Гц







- Поддержка технологии AMD Steady VideoTM 2.0: новая функция







постобработки видеоизображения для автоматического устранения







дрожания при просмотре домашних и онлайновых видеозаписей







- Поддержка функции HDCP через разъемы DVI







- Подержат Blu-луч 1080p (КОММУТАЦИОННАЯ ДОСКА) /







воспроизведение HD-DVD через разъемы DVI





Аудиосистема

- 5.1 CH HD Аудио HD (Кодер-декодер Аудио Realtek ALC662)





ЛВС

- PCIE x 1 Gigabit LAN 10/100/1000 Mb/s







- Realtek RTL8111E











- поддержка Wake-On-LAN



Русский



- Поддержка определения кабеля ЛВС











- Поддержка энергосберегающего интерфейса Ethernet 802.3az







- Поддержка PXE





Разъемы ввода-

I/O Panel





вывода на задней

- 1 x порт мыши PS/2







панели

- 1 x порт клавиатуры PS/2







- 1 x D-Sub порт





27

ASRock FM2A75M-DGS R2.0 Motherboard

Image 27
