Samsung HW-K560/XE WHAT’S Included, Before Reading the USER’S Manual, ++Icons used in this manual

Page 5

GETTING STARTED

WHAT’S INCLUDED

BEFORE READING THE USER’S MANUAL

Note the following terms before reading the user manual.

++Icons used in this manual

Icon

Term

Definition



Caution

Indicates a situation where a function does not operate or settings may be cancelled.









Note

Indicates tips or instructions on the page that help you operate a function.







Check for the supplied accessories shown below.

ENG

Remote Control /





Power Cord : 2 EA

AC/DC Adapter

Lithium Battery (3V : CR2032)































A

B

CENTER LINE

A-TYPE : 616mm

B

A













B-TYPE : 360mm















Wall Mount Guide







Holder-Screw : 2 EA

Bracket-Wall Mount L

Bracket-Wall Mount R

Screw : 2 EA

The appearance of the accessories may differ slightly from the illustrations above.

Micro USB to USB adapter and HDMI cables are sold separately. To purchase, contact a Samsung Service Centre or Samsung Customer Care.

5
