Samsung DVD-SR270M/XEU Tour of the Remote Control, DVD Button, Press this when you use a DVD

Page 17

Tour of the Remote Control

Your DVD Recorder remote control will work with Samsung televisions and compatible brands.

1

20

2

21

3 22 23

4

5

24

6



7

25

8

26

9

27

10

28



11



12

29

13



14

30

15

31

16



17

32

18

33

19

34

1.TV Button

Press this to operate TV.

2.DVD Button

Press this when you use a DVD.

3.STANDBY/ON Button

4.Number Button

5.TV/DVD Button

6.Reverse/Forward Skip Buttons

Press to skip a disc backwards or forwards.

7.TV MUTE Button

This operates as sound mute (TV mode).

8.FAV LIST

When you use DTV, press this button to switch between favourite list.

9.STOP button Press to stop a disc.

10.TV VOL (Volume) Button TV volume adjustment.

11.DTV/ANALOG Button

Select Digital/Analogue broadcasting.

12.MENU Button

Brings up the DVD Recorder’s setup menu.

13.OK/Direction Buttons (▲/▼/◄/►Buttons)

14.TITLE LIST/DISC MENU Button

Press this to enter the Title List/Disc menu.

15.AUDIO Button

Use this to access various audio functions on a disc (DVD mode) .

16.A, B, C, D button

Press this when you use DTV functions.

17.ANYKEY Button

Press this to view the status of the disc that is being played.

18.REC Button

Press this to make a recording on DVD-RAM/DVD±RW/+R discs.

19. INFO button

Press to display the programme information box in the screen when you use DTV.

20.INPUT SEL. Button

Select input signal in external input mode (Prog, AV1, AV2, AV3 or DV input).

21.TV/RADIO Button

In DTV mode, press this button to switch TV or Radio mode.

22.TV STANDBY/ON Button

23.OPEN/CLOSE Button

To open and close the disc tray.

24.SUBTITLE Button

Press this to switch the DVD’s subtitle language.

25.PAUSE Button Press to pause a disc.

26.TEXT Button

When you use DTV, press this button to select the Digital text OSD.

27.PLAY Button

Press to play playback/recording.

28.PROG Button

Press this to select a TV channel

29.RETURN Button

Returns to previous menu.

30.PLAY LIST/TITLE MENU Button

Press this to enter the Edit playlist/Title menu.

31.EXIT Button

32.GUIDE Button

Press this to switch programme guide.

33.REC MODE Button

Press this to set the desired recording time and picture quality.

34.CANCEL Button

Connecting & Setting Up

English - 17
