Samsung RF858VALASL/EU manual Changing the Water Filter, Ice Off Hold 3 sec

Page 24

( 5 ) Fridge (Hold 3sec for Power Cool)

Touch this button to set the fridge to your desired temperature. You can set the temperature between 1 °C and 7 °C. Touch and hold this button for 3 seconds to decrease the time needed to cool products in the Refrigerator. This can be helpful if you need to quickly cool easily spoiled items or if the temperature in the fridge has warmed dramatically (For example, if the door was left open).

( 6 ) Lighting (Hold 3 sec for child lock)

Touching this button sets the Dispenser LED lamp (under the display) to continuous mode so that it stays on continuously.

The button also lights up. If you want the Dispenser lamp to come on only when some one uses the dispenser, touch this button to turn the continuous mode off. Also, pressing this button for 3 seconds turns on Child Lock which locks the display panel and dispenser buttons so the buttons can not be used. The Child Lock icon lights up to indicate you’ve activated the Child Lock function. Press 3 seconds to unlock.

( 7 ) Ice Type

Press the Ice Type button to change the ice type. Each time you press the Ice Type button, the cubed and crushed ice modes alternate and the Cubed or Crushed ice icon lights up, indicating your selection.

If you don’t need ice, turn the function off to save on water and energy consumption (See Ice Off below).

( 8 ) Ice Off (Hold 3 sec)

Press the Ice Off button for 3 seconds until the Ice Off Indicator ( ) illuminates.

( 9 ) Filter

Water filter usage

This icon will light up when you need to change the filter. After you use about 300 gallons of water, the filter indicator lights up. (in about 6 months). The icon will blink red for several seconds when you open or close the door.

After you install the new water filter, reset the filter indicator by pressing the Alarm/ hold 3 sec for Filter Reset button.

If water is not dispensing or dispensing slowly, you need to replace the water

filter because the water filter is clogged.

Some areas have large amounts of lime in their water, which causes the water filter to clog more quickly.

24_ operating

CHANGING THE WATER FILTER

To reduce risk of water damage to your WARNING property DO NOT use generic brands

of water filters in your SAMSUNG Refrigerator.

USE ONLY SAMSUNG BRAND WATER FILTERS. SAMSUNG will not be legally responsible for any damage, including, but not limited to, property damage caused by water leakage from the use of a generic water filter. SAMSUNG Refrigerators are designed to work ONLY WITH SAMSUNG Water Filter.

The Filter light turns red to let you know

when it is time to change your water filter cartridge.

To give you time to get a new filter,



the red light comes on just before the

(Red)

capacity of the current filter runs out.



Changing the filter on time provides you with the freshest, cleanest water from your refrigerator.

1.Shut off the water supply. Then, turn the water filter ( 1 ) about 1/4 turn, counter-clockwise.

2.Pull the water filter ( 1 ) from the case filter ( 2 ).

2

1

• To change the water filter more easily, shut off the water supply valve.

• Sometimes, it is hard to disassemble the water

filter because impurities in the

water cause it to

stick. If you are having difficulties, grip the water

filter firmly and pull it hard.



• When you pull out



the water filter, a little

2

water can leak from

3

the opening. This is



normal. To minimize



the water leaks, keep the filter

cartridge

horizontal when you pull it.



To prevent overflow, empty the water filter tray ( 3 ) and dry around the filter case ( 2 ).

3.Insert the new filter into the filter case (4 ).

4.Push the filter in, and then turn it clockwise until it locks.

If you have trouble inserting the water filter because of high water pressure, shut off the water supply valve.

DA68-02836K (EN)-08.indd 24

2015. 8. 26.

�� 11:37
