Crimestopper Security Products CS-2002DC Power Door Lock Wiring, PIN Sensor PLUG/HARNESS Blue

Page 6

WIRING

RED WIRE: +12V POWER INPUT (15 amp fuse)

Connect to +12 Volt source with supplied fuse & holder. Recommended location for this connection is at the vehicle battery positive terminal.

14 GA. BROWN WIRE: (On-board Starter Disable Relay)

Cut the 14GA. Brown wire in half. Connect the 2 female terminals to the Male terminals on the control module. Cut the starter (Cranking only) wire on the vehicle. Connect the two brown wires to the 2 ends of the Starter wires. See SYSTEM WIRING DIAGRAM on PAGE 19

2 PIN PLUG (BLUE): PROGRAM/OVERRIDE PUSH BUTTON

Mount the Valet/Programming switch in a concealed but accessible location. This button is required when programming options and when an emergency override is required.

2 PIN PLUG (RED): LED INDICATOR (RED FLASHING LIGHT) Mount the LED in a visible location of the dash or console.

4 PIN SENSOR PLUG/HARNESS (BLUE):

White Wire: Negative Trigger

Blue Wire: Negative Warn-away

Black Wire: Sensor Ground Red Wire Sensor Power

SHOCK SENSOR: The sensor supplied with this system does not require any additional wiring. Simply mount the sensor in a suitable location, plug it in, and adjust the sensitivity. There are 2 LED’s on the shock sensor to assist you in adjusting sensitivity. The Green LED indicates the “Warn Away” level and the Red LED indicates a full alarm shock sensor violation.

POWER DOOR LOCK WIRING

3 PIN DOOR LOCK PLUG (Optional):

GREEN: (-) Negative pulse for LOCK

RED: +12V Coil Power for using relays.

BLUE: (-) Negative pulse for UNLOCK

Hint: Determine the type of locking system the vehicle has before connecting any wires. Incorrect connection could result in damage to the alarm and/or the vehicle’s locking system.
