Kenmore 625.348321 owner manual Water Softener START-UP 1E. Fill the Storage Tank with Salt

Page 8

SECTION 1

WATER SOFTENER START-UP

1E. FILL THE STORAGE TANK WITH SALT

Brine (salt dissolved in water) is needed for each FIG. 4 and every regeneration. The water for making

brine is metered into the salt storage tank by the softener. However, you must keep the tank filled with salt.

Fill the tank with NUGGET or PELLET water softener salt. DO NOT use rock salts, as they have dirt and sediments that will stop the softener from working.

Before filling, be sure the brinewell cover is in place on the top of the brinewell. Salt storage capacity is shown on page 21.

NOTES:



In humid areas, it is best to fill the storage tank



half-full, and to refill it more often. Salt bridging



(see page 14) occurs more often when conditions



are humid.



WATER SOFTENING SALT WITH IRON RE-



MOVING ADDITIVES — Some salts have an



additive to help the softener handle iron in the



water supply. Although this additive may help

SODIUM INFORMATION: Water softeners us-

to keep the softener resin clean, it may also

release corrosive fumes that will weaken and

ing sodium chloride for regeneration add so-

shorten the life of some softener parts.

dium to the water. Persons who are on sodium



restricted diets should consider the added so-



dium as part of their overall sodium intake.



For example, if your water supply is 15 grains



hard, you would have to drink 3 quarts of



softened water to consume 335 milligrams of



sodium. That is equivalent to eating 2-1/2 slices



of white bread.



Persons who are concerned about their drinking



water should consider a Sears Drinking Water



System that will remove or reduce in excess of



90% of the sodium and other drinking water



contaminants.

YOU HAVE NOW FINISHED THE WATER SOFTENER START UP. AFTER THE SANITIZING RE- CHARGE, ON PAGE 7, THE SOFTENER WILL BE GIVING YOU SOFT WATER.

8

Page 7 Page 9
Image 8
Page 7 Page 9
Contents OWNER’S Manual Save this ManualFull TEN Year Warranty Against Leaks WarrantyFull ONE Year Warranty on Water Softener Table of Contents Service Tech InformationRepair Parts Softener Start UPWater Softener START-UP Safety Guides Section1B. Check List of ALL STEP-BY-STEP Guides to Install Water Softener START-UPWater Softener START-UP 1C.PROGRAM the Timer SET the TimerSee page 9 for Other Timer Controls and Features SET Time of DAYWater Softener START-UP 1D. Sanitizing the Water Softener Water Softener START-UP 1E. Fill the Storage Tank with Salt Water Softening Salt with Iron REHOW Your Water Softener Works Face Plate Timer Features HOW Your Water Softener Works 2A. Face Plate Timer Features Flashing display is to remind you to reset the timerService RegenerationWater Flow Through the Softener in Brining and Brine Rinse Automatic Bypass Please see page 8 for Salt Filling Directions Salt Bridge Salt BridgeCare of Your Softener 3B. Keeping the Water Softener Clean CoversnoteNozzle and Venturi Iron from the Resin BEDKeep the Softener from Freezing SoftenerProblem Cause Correction No Soft WaterOther Things to Know 4A. HOW to FINE-TUNE Your Softener SET Days and Time of REGENERA- TION, or RechargeSET the Fill Cycle Minutes Other Things to Know HOW to FINE-TUNE Your Softener See Instructions for Using the TABLE,Other Things to Know 4B. DIMENSIONS/SPECIFICATIONS InchesService TECH. Information 5A. Electrical Connections Faceplate TimerService TECH. Information 5B. Regeneration Cycle Times See Regeneration Table on page 20, and SPECIFICATIONS,Manual Advance Diagnostic Service TECH. Information 5C.TROUBLESHOOTINGAutomatic Electronic Diagnostics Brine Valve Float Setting Freeboard Measurement Section Service TECH. Information 5D.ROTARY Valve Service DisassemblyAssembly Servicing the ValveService Cycle Fill CycleBrining and Brine Rinse Cycles Backwash CycleFast Rinse Cycle Service TECH. Information Sears Water Softener Repair Parts Brine Valve Assembly KEY Part Description NumberValve Assembly Parts List Bypass Installation Valve Model noSolid State

625.348321 specifications

The Kenmore 625.348321 is a highly regarded model in the realm of water softeners, designed to alleviate the challenges posed by hard water in households. This unit effectively addresses the mineral buildup caused by calcium and magnesium ions, improving water quality and enhancing the longevity of plumbing fixtures, appliances, and laundry.

One of the standout features of the Kenmore 625.348321 is its impressive grain capacity. With a capacity of 31,000 grains, it is well-suited for medium to large households. This ensures that families experience consistent and reliable soft water, preventing the telltale signs of hard water, such as scale buildup and dry skin.

The unit employs a powerful ion exchange technology, a widely recognized method for softening water. The process involves exchanging the hard water minerals for sodium ions, effectively capturing the unwanted hardness and leaving users with soft, palatable water. This not only enhances the efficiency of soaps and detergents but also promotes the health of plumbing systems and appliances by preventing mineral deposits.

An additional feature is its demand-initiated regeneration system. This technology allows the unit to monitor water usage and regenerate only when necessary, which results in reduced salt and water consumption. This energy-efficient approach not only helps lower utility bills but also contributes to a more sustainable household environment.

The Kenmore 625.348321 also boasts user-friendly programming options, enabling homeowners to easily set and adjust preferences for optimal performance. The intuitive interface allows for quick access to diagnostics and system performance, ensuring that users are well-informed about the status of their water softening system.

Moreover, this model is equipped with a large brine tank that can hold a significant amount of salt, minimizing the frequency of refills and simplifying maintenance. With its compact design, the water softener fits seamlessly into various spaces, making it a convenient choice for homes with limited installation areas.

In summary, the Kenmore 625.348321 stands out as an effective water softener, combining advanced technology with user-friendly features. It provides households with the benefits of soft water, ensuring cleaner clothes, softer skin, and extended appliance life—all key advantages for any modern home.
