Avanti IMW24, IMP25 instruction manual Operating Your ICE Maker, Stop, Select, Alert, Ice Full

Page 10

?Electrical connection

?WARNING?

IMPROPER USE OF THE GROUNDED PLUG CAN RESULT IN THE RISK OF ELECTRICAL SHOCK. IF THE POWER CORD IS DAMAGED, HAVE IT REPLACED BY AN AUTHORIZED AVANTI PRODUCTS SERVICE CENTER.

?This ice maker should be properly grounded for your safety. The power cord of this ice maker is equipped with a three-prong plug which mates with standard three prong wall outlets to minimize the possibility of electrical shock.

?Do not under any circumstances cut or remove the third ground prong from the power cord supplied.

?Never use an extension cord to connect power to the unit.

?Never use a two -prong grounding ad apter.

?Where a two-prong wall receptacle is encountered, contact a qualified electrician to have it replaced with a 3-prong receptacle in accordance with applicable electrical codes.

?This ice maker requires a standard 115/120 volts a.c.~/60hz electrical outlet with three -prong ground.

?The cord should be secured behind the ice maker and not left exposed or dangling to prevent accidental injury.

?Extension cord

Because of potential safety hazards under certain conditions, it is strongly recommended that you do not use an extension cord with this appliance. However, if you must use an extension cord it is absolutely necessary that it be a UL/CUL -listed, 3-wire grounding type appliance extension cord having a grounding type plug and outlet and that the electrical rating of the cord be 115 volts and at least 10 amperes.

OPERATING YOUR ICE MAKER

?Control Panel Operation Start

Press to turn unit on. This button is also used to start the ice making cycle.

Stop

Press to turn unit off.

Select

ICE SIZE SELECTION of (S) small, (M) medium or (L) large. (The chosen mode shall stay as selected unless changed or there is a power failure).

Please select the (S) when ambient temperature is below 15°C (59ºF).

Alert

ADD WATER INDICATOR. The ”Alert ” light will come on with a beep sound. Add water and press “STOP” button and then press “START” button to restart the icemaker.

Ice Full

ICE FULL INDICATOR. This light will come on with a beep sound which indicates that the storage cabinet is full. Press the “STOP” button and remove the ice cubes then, press the “START” button to restart the Ice maker.

IMPORTANT: YOU MUST PRESS “STOP”. THEN THE “START” BUTTON TO RESTART THE ICE MAKER AFTER YOU ADD WATER OR REMOVE SOME OF THE ICE CUBES.

10
