Heatcraft Refrigeration Products H-ENGM0408, H-ENGM0806 manual Inches Type Ceiling Walls Floor

Page 9

Refrigeration Load Estimate Form

(for rooms above 32ºF) Bulletin Above32-05

Estimate for:

Estimate by:

Date:

Basis for Estimate









Room Dimensions: Width



ft. x Length

ft. x Height

ft.

Volume: (L)

x (W)

x (H)

=

cu. ft.

Ambient Temp

ºF. (Corrected for sun load) — Room Temp

ºF. =

Note: Tables can be found in Engineering Manual, H-ENG-2

ºF. T.D.



Insulation

Inches

Type

Ceiling

Walls

Floor

Product Load







(a)

lbs./day of

to be reduced from entering

temp. of

ºF. to

ºF. Temp. Drop

ºF.

(b)

lbs./day of

to be reduced from entering

temp. of

ºF. to

ºF. Temp. Drop

ºF.

Miscellaneous



















Motors (including all blower motors)



HP

Ground Temp.

(Table 21)

Lights (assume 1 watt/sq.ft.)



Watts





No. of people















































1. Transmission Loads



















Ceiling: (L)



x (W)

x Heat Load

(Table 1)

=

North Wall: (L)



x

(H)





x Heat Load

(Table 1)

=

South Wall: (L)



x







x Heat Load

(Table 1)

=



(H)

East Wall:







x







x Heat Load

(Table 1)

=

(W)



(H)





West Wall:











x







x Heat Load

(Table 1)

=







(H)







(W)







Floor: (L)



x (W)

x Heat Load

(Table 1)

=





























2. Air Change Load



















Volume:



cu. ft. x

Factor (Table 4) x

Factor (Table 6)

=





























3. Additional Loads



















Electrical Motors:





HP x 75000 BTU/HP/24 hr.



=

Electrical Lights:



Watts x 82





=

People Load:



People x

BTU/24 hrs. (Table 12)



=

Glass Door Load:





Doors x 19200 BTU/Door/24 hr.



=























4. Product Load: Sensible

(Product Load Figured @ 24 hr. Pulldown*)





(a)

lbs./day x

Spec. Heat (Table 7) x

ºF. Temp Drop

=

(b)

lbs./day x

Spec. Heat (Table 7) x

ºF. Temp Drop

=

*For product pulldown time other than 24 hrs. figure 24 hr. load x (24/Pulldown Time)



























5. Product Load: Respiration*









(a)



lbs. stored x



BTU/lbs./24 hrs. (Table 8)

=

(b)



lbs. stored x



BTU/lbs./24 hrs. (Table 8)

=

*For consideration of previously loaded product, a multiplier of (5) is normally applied to the daily

product load (Line #4)































Total Refrigeration Load (1+2+3+4+5) BTU/24 hrs.







Add 10% Safety Factor









Total with Safety/Factor BTU/24 hrs.



























Divide by No. of Operating Hrs. (16) to obtain BTUH Cooling Requirement



















































Equipment Selection





Condensing Unit



Unit Cooler

System Capacity

Qty.



Model No.

Qty.

Model No.



BTU/hr.

2175 West Park Place Blvd. • Stone Mountain, GA 30087 • 770.465.5600 • Fax: 770.465.5990 • www.heatcraftrpd.com

9
