Frigidaire 318200404 manual Cleaning the Regular Oven Non self-clean oven

Page 17

Cleaning the Appliance (continued)

Cleaning the Regular Oven (Non self-clean oven)

Make sure the oven is cool and that all control knobs are at OFF “ ” position. Cleaning the oven is a lot easier when the door is removed.

1.Remove the oven door; see page 16.

2.Empty the oven including the racks.

3.You can wash the broiler pan, grid and racks in the kitchen sink.

4.Clean oven lining thoroughly with soap and a wet cloth and wipe with a dry cloth.

To remove burned-on fat on oven walls, moisten soiled parts with household ammonia, using a wet cloth.

Follow suggested manufacturer’s cleaning method. (Do not remove the oven door when using ammonia.)

Complete cleaning with a damp cloth and use a fine steel wool or scouring agent if necessary.

The lower element can be moved up for cleaning purposes.

5.Replace racks in the oven. Reinstall oven door.

Cleaning the Self-Clean Oven (some models)

Adhere to the following cleaning precautions:

•Allow the oven to cool before cleaning.

•Wear rubber gloves when cleaning any exterior parts of the oven manually.

During the self-cleaning cycle, the outside of the wall oven can become very hot to the touch. DO NOT leave small children unattended near the appliance.

The health of some birds is extremely sensitive to the fumes given off during the self-cleaning cycle of any range. Move birds to another well ventilated room.

Before cleaning any part of the oven, be sure the electronic oven control is turned off or else push CANCEL pad. Wait until the oven is cool.

DO NOT use commercial oven cleaners or oven protective coatings in or around any part of the self-cleaning oven. DO NOT clean the oven door gasket. The gasket on the oven door is essential for a good seal. Care should be taken not to rub, damage or move the gasket. DO NOT use any cleaning materials on the gasket. Doing so could damage it. DO NOT use aluminum foil to line the oven bottom. This may affect cooking or foil could melt and damage the oven surface.

A self-cleaning oven cleans itself with high temperatures (well above cooking temperatures) which eliminate soil completely or reduce it to a fine powdered ash you can whisk away with a damp cloth.

Preparing the Oven for Self-Cleaning

DO HAND CLEAN DOOR

DO HAND

CLEAN

FRAME

DO NOT HAND CLEAN SEAL

1.Remove any excess spillovers in the oven cavity before starting the self-cleaning cycle. To clean, use hot soapy water and a cloth. Large spillovers can cause heavy smoke or fire when subjected to high temperatures. DO NOT allow food spills with a high sugar or acid content (such as tomatoes, sauerkraut, fruit juices or pie filling) to remain on the surface as they may cause a dull spot even after cleaning.

2.Clean any soil from the oven frame and the door liner (see illustration). These areas heat sufficiently during a self-clean cycle to burn soil on. Clean with soap and water.

3.Remove the broiler pan and insert, all utensils and any foil. These items do not withstand high cleaning temperatures.

4.Oven racks may be left in the oven or may be removed. If they go through the clean cycle, their colour will turn slightly dull. After the cycle is completed and the oven has cooled, rub the sides of the racks with wax paper or a cloth containing a small amount of baby oil or salad oil. This will make the racks glide easier.

General 15 Information

Page 16 Page 18
Image 17
Page 16 Page 18
Contents Electric Ranges N e r ’ s I d e Warranty Applies to Frigidaire Parts and ServiceWarranty does not Apply to WarrantorN e r a l I n f o r m a t i o n Do not Touch Surface UNITS, Areas Near These Important Instructions for UsingImportant Instructions for Using Your Oven Important Instructions for Cleaning Your RangeSELF-CLEANING Ovens Your CooktopClearances and Dimensions Installation InstructionsLocation LevelingElements are Cool Oven LightSurface Light Circuit Protection Setting Surface ControlsSelecting Surface Cooking Utensils GoodAir Circulation in the Oven Convection Roasting some modelsConvection Cooking Convection notesOven Baking Indicator LightBaking Problems and Solutions Chart Broiling Oven SettingsTypes of Heating Units Used Ceramic Glass Cooktop some modelsSpecial Caution for Aluminum Foil Aluminum Cooking Utensils HOT Surface Indicator LightThings to Remember USE and Care of Glass SurfaceDo not USE on Ceramic Glass Cooktop Cleaning Materials for Ceramic Glass CooktopDo USE on Ceramic Glass Cooktop Surfaces Cleaning Agents Instructions Cleaning the ApplianceControl Panel Coil Surface Elements some modelsDaily Cleaning Porcelain enamel cooktop cleaning instructionsPorcelain Enamel Cooktop Cleaning Cleaning the Self-Clean Oven some models Cleaning the Regular Oven Non self-clean ovenPreparing the Oven for Self-Cleaning Adhere to the following cleaning precautionsSetting the Controls for a Clean Cycle What to Expect During CleaningTo Remove and Replace the Oven Door Automatic Lock OFF of the Surface ElementsTo Remove/Replace Storage Drawer Removable Outer Door Glass Panel some modelsTo remove the external door glass panel To replace the external door panelStaple or clip original invoice here Range does not Operate InstallationProblem Possible Cause / Solution Surface Units Range does not OperatePoor Baking Results Avoid Transportation Damage to Your Range BroilingSetting Warmer Drawer Controls To Replace Warmer Drawer General CleaningTo Remove Warmer Drawer Cuisinières Électriques Guide de ’utilisateur Garant Frigidaire Pièces ET ServiceLA Garantie Sapplique LA Garantie NE Sapplique PASF o r m a t i o n s g é n é r a l e s Importantes Mesures DE Sécurité Instructions Importantes Pour L’UTILISATION DE Votre Four Pour Surface DE Cuisson Vitrocéramique SeulementConservez CES Instructions Fours AutonettoyantsEmplacement Espaces prévus et dimensionsNivellement VUE DE ’AVANT CôtéLampe DE Surface Installée Instructions d’installation suiteLampe du four Certain modèles Pour mettre la cuisinière de niveauBON Coupe-circuit de protectionMauvais Réglage Type de cuissonCirculation d’air dans le four Rôtissage par convection certains modèlesCuisson par convection Option disponible avec certains modèlesCuisson au four Voyants lumineuxRéglage du four Cuisson au grilTypes DE Foyers Utilisés Surface de cuisson vitrocéramique certains modèlesVoyant Avertisseur DE Surface Chaude Surface de cuisson vitrocéramique certains modèles suitePoints À SE Rappeler Entretien DE LA Surface DE CuissonComment Nettoyer LA Surface DE Cuisson Vitrocéramique Certains modèles suiteNE PAS Utiliser SUR LA Surface DE Cuisson Vitrocéramique AvertissementNettoyage de l’appareil Tableau des commandesNettoyage extérieur Surface de cuisson à foyers spiralés certains modèlesNettoyage Quotidien Nettoyage de l’appareil suiteNettoyage DE LA Surface DE Cuisson EN Émail Vitrifié Nettoyage du four autonettoyant certains modèles Nettoyage du four régulier four non autonettoyantPréparation du four avant l’autonettoyage Prenez les précautions de nettoyage qui suiventRéglage des commandes du four Enlever et réinstaller la porteCe qui peut survenir durant l’autonettoyage Table de cuisson levable certains modèlesPorte avec vitre extérieure démontable certains modèles Pour réinstaller la vitre extérieure de la porteRetirer/replacer le tiroir de rangement Pour retirer la vitre extérieure de la porteBrocher ici votre facture LA Cuisinière NE Fonctionne PAS Problèmecause Possible / SolutionSurface DE Cuisson LA Cuisinière NE Fonctionne PAS suiteMauvais Résultats DE Cuisson AU Four Évitez D’ENDOMMAGER L’APPAREIL Durant SON Transport Problème Cause Possible / SolutionCuisson AU Gril Tiroir-réchaud Commandes duRéglage des Nettoyage général Suite

318200404 specifications

The Frigidaire 318200404 is a high-quality replacement oven igniter designed to enhance the functionality and reliability of gas appliances. Its design ensures that it ignites the gas burner effectively, delivering consistent performance vital for cooking and baking. This igniter is primarily used in various Frigidaire gas ranges and ovens, making it an essential component for maintaining optimal cooking conditions.

One of the main features of the Frigidaire 318200404 is its durable construction. Made from high-temperature resistant materials, it can withstand the intense heat produced in the oven, ensuring longevity and reliability. This durability is crucial, as igniters are subjected to thermal stress during regular use. Additionally, the Frigidaire igniter is designed to provide a stable ignition source, minimizing the risk of gas build-up, which can occur if the igniter fails to activate promptly.

The technology behind the Frigidaire 318200404 involves a ceramic insulator combined with a metal filament. This combination allows for efficient heat generation, resulting in a quicker and more reliable ignition process. The igniter is engineered to provide a slow build-up of heat, which is ideal for igniting larger burners, ensuring that meals cook evenly and reduce the likelihood of burning.

Another characteristic of the Frigidaire 318200404 is its ease of installation. It typically features a straightforward plug-in design that allows homeowners and technicians to replace faulty igniters with minimal tools and effort. This ease of replacement reduces downtime for ovens and ensures that cooking appliances remain functional with little disruption to the household routine.

Moreover, the 318200404 igniter is compatible with various Frigidaire models, making it a versatile choice for many users. Proper maintenance of the oven igniter is crucial, as regular inspections can prevent significant issues and extend the lifespan of the appliance.

In summary, the Frigidaire 318200404 is a reliable and efficient igniter that plays an essential role in gas cooking appliances. Its durable construction, advanced technology, and easy installation make it an ideal choice for homeowners looking to maintain the performance of their ovens and ranges. Proper attention to the igniter can significantly enhance the overall cooking experience.
