Setting Oven Controls

Setting Continuous Bake or 12 Hour Energy Saving

The TIMER ON/OFF and CLEAN pads control the Continuous Bake or 12 Hour Energy Saving features. The oven control has a factory preset built-in 12 Hour Energy Saving feature that will shut off the oven if the oven control is left on for more than 11 hours and 59 minutes. The oven can be programmed to override this feature for Continuous Baking.

INSTRUCTIONS

PRESS

DISPLAY

To set the control for Continuous Bake or 12 Hour

Energy Saving features:

1. Press and hold

for 6 seconds (Fig.1). "12 Hr" or "- - Hr"

for 6 seconds

will appear in the display and the control will beep once.

2. Press to switch between the 12 Hour Energy Saving and

continuous bake features. Note: "12 Hr" (Fig. 2) in the display indicates the control is set for 12 Hour Energy Saving feature and "- - Hr" (Fig. 3) indicates the control is set for the Continuous Bake feature.

3. Press

to accept the change (Fig. 4; display will return to

or

Fig. 1

Fig. 2

Fig. 3

time of day) or press to reject the change.

Setting Kitchen Timer

Fig. 4

The TIMER ON/OFF pad controls the Kitchen Timer feature. The Kitchen Timer serves as an extra timer in the kitchen

that will beep when the set time has run out. It does not start or stop cooking. The Kitchen Timer feature can be used during any of the other oven control functions. Refer to "Minumum & Maximum Control Pad Settings" on page 9 for time amount settings.

INSTRUCTIONS

PRESS

DISPLAY

To set the Kitchen Timer (example for 5 minutes):

1. Press . "0:00" will appear and "TIMER" will flash in the display (Fig. 5).

Fig. 5

2.Press the number pads to set the desired time in the display

(example ). Press . The time will count down with "5:00" and "TIMER" will show in the display (Fig. 6).

Note: If is not pressed the timer will return to the time of day.

3.When the set time has run out, "End" and "TIMER" will show in the display (Fig. 7). The clock will sound with 3 beeps every 15

seconds until is pressed.

To cancel the Kitchen Timer before the set time has run out:

Press . The display will return to the time of day.

Fig. 6

Fig. 7

11
