Sharp R-22AT, R-24AT Replace the Mains Plug, Alling for Service, Earth, Neutral, Live

Page 31

T

O REPLACE THE MAINS PLUG

The wires in the mains cable are colour coded as shown opposite:

As the colours of the cores in the mains lead of your oven may not correspond with the coloured marking identifying the terminals in your plug, connect the wires as shown:

Make sure the terminal screws are tight and the cable is held securely by the cable grip where it enters the plug. Like most appliances in your home, your oven must be con- nected to a single phase 230-240 Volt, 50Hz alternating cur- rent supply.

If you do not make the proper electrical connections you might damage the oven or injure yourself. Neither SHARP nor the supplier will be liable if this happens.

green and yellow stripes

=

EARTH

blue

=

NEUTRAL

brown

=

LIVE

•The green and yellow wire to the plug terminal marked E or or coloured green or coloured green and yellow.

•The blue wire to the plug terminal maked N or coloured black or coloured blue.

•The brown wire to the plug terminal marked L or coloured red or coloured brown.

!WARNING:

THIS APPLIANCE MUST BE EARTHED.

IF YOU HAVE ANY DOUBTS ABOUT YOUR ELECTRICAL SUPPLY ASK A QUALIFIED ELECTRICIAN.

C

ALLING FOR SERVICE

•If you are unable to resolve a problem using the checks covered on the last few pages, do not attempt to serv- ice this microwave oven yourself.

•Contact the dealer or supplier from whom the oven was purchased in order to obtain service. Where this is not possible, please contact the SHARP Customer Infor- mation Centre, telephone:

08705 274277 (office hours).

•For general information & assistance with oven que- ries, please contact our

Customer Information Centre:

U.K.: 08705 274277 (office hours)

Ireland: 01 676 0648 (office hours)

Website: http://www.sharp.co.uk/support

•Replacement accessories may be obtained from our main parts distributor Willow Vale Electronics Ltd. Telephone: 0121 766 5414

30

Page 30 Page 32
Image 31
Page 30 Page 32
