Gardena 1559 manual Troubleshooting, Clean nozzles Clean protective panel of solar cell

Clean nozzles:

A

GB D

B

Clean protective panel of solar cell:

If the watering pattern is no longer even, the nozzles can be cleaned using the cleaning needle provided.

1. Open both locks A and raise the cover B.

2.	Turn the cleaning needle D	E
	(e.g. with a coin) anticlockwise
	through 180° 1 and pull out
	carefully 2 (bayonet coupling).
3.	Clean nozzles E with cleaning	D
	needle D.

4.Refit cleaning needle D in reverse order.

5.Close cover B and both locks A.

To make sure that the rechargeable battery is always sufficiently charged, the protective panel of the solar cell has to be cleaned if soiled.

No caustic / abrasive cleaning agents or hard objects should be used.

vClean protective panel of solar cell with a damp cloth.

8. Troubleshooting

Fault	Possible cause	Remedy
Irrigation width smaller than	Dirt filter soiled.	v Clean dirt filter.
on initial start-up
	Tap not opened sufficiently.	v Open tap further.
	Water pressure too low.	v Increase water pressure /
		water supply.

Rechargeable batteries almost flat (Auto and Set LED flashing) / Protective panel of solar cells soiled.

vEnsure solar cells are exposed to sufficient sunlight / clean protective panel. If the rechargeable battery is almost flat, the range is reduced to the min. level.

	Large-area pop-up irrigation	v Press OK button.
	is in energy-saving mode
	(4 weeks without energy
	supply or operation).
	Irrigation range is programmed	v Reprogramme irrigation
	incorrectly.	range.
Watering pattern uneven	Nozzles soiled.	v Clean nozzles.
	Nozzle head soiled.	v Clean nozzle head.
	Nozzle head damaged.	v Contact GARDENA Service.
Auto and Set LED flashing	Rechargeable batteries almost	v Ensure solar cell is exposed
simultaneously	discharged.	to sufficient sunlight.

16
