| Specifications | |
|
|
|
|
| ||
|
|
|
|
|
|
|
|
| Table 1. Generator Specifications |
|
| ||
| Model |
| ||||
| Type | Revolving field, self ventilated, |
| |||
| open protected type synchronous generator |
| ||||
|
|
| ||||
| Armature Connection | Star with Neutral |
| Zigzag |
| |
| Phase | 3 |
|
| Single |
|
| Standby Output | 77 kVA (62 kW) |
| 44 KW |
| |
| Prime Output | 70 kVA (56 KW) |
| 40 KW |
| |
| Voltage | 240 or 480V |
| 240 or 120V |
| |
|
|
|
|
|
| |
| Frequency | 60 Hz |
| |||
| Speed | 1800 rpm |
| |||
| Power Factor | 0.8 |
|
| 1.0 |
|
| Aux. AC Power | Single Phase, 60 Hz |
| |||
| Voltage | 120V |
|
| ||
| Output | 4.8 Kw (2.4 kW x 2) |
| |||
| Weight (No Fuel) | 3,771 lbs. (1,710 kg) |
| |||
| Weight (Fuel) | 4,553 lbs. (2,065 kg) |
| |||
| Maximum Lifting Capacity | 14,050 lbs. (6,370 kg) |
| |||
|
| Table 2. Engine Specifications |
|
| ||
| Model | ISUZU |
| |||
| Type | 4 cycle, |
| |||
| air to air intercooled |
| ||||
|
|
| ||||
| No. of Cylinders | 4 cylinders |
| |||
| Bore x Stroke | 3.76 in. x 4.13 in. (95.4 mm x 105 mm) |
| |||
| Displacement | 183 cu. in. (3,000 cc) |
| |||
| Rated Output | 87.4 HP/1800 RPM |
| |||
| Starting | Electric |
| |||
| Coolant Capacity | 3.57 gal. (13.5 liters) |
| |||
| Lube Oil Capacity | 3.96 gal. (15.0 liters) |
| |||
| Fuel Type | #2 Diesel Fuel |
| |||
| Fuel Tank Capacity | 103 gal. (390 liters) |
| |||
| Fuel Consumption | 4.1 gal. (15.4 L)/hr at full load |
| 3.1 gal. (11.9 L)/hr at 3/4 load |
| |
| 2.1 gal. (8.10 L)/hr at 1/2 load |
|
| 1.3 gal. (4.80 L)/hr at 1/4 load |
| |
|
|
|
| |||
| Battery | 12V 72Ah x 1 |
| |||
