Flymo Turbo Compact manual Cables

3.Do not use the lawnmower if the electric cables are damaged or worn

4.Immediately disconnect from the mains electricity sup- ply if the cable is cut, or the insulation is damaged. Do not touch the electric cable until the electrical supply has been disconnected. Do not repair a cut or dam- aged cable. Replace it with a new one.

5.Your extension cable must be uncoiled, coiled cables can overheat and reduce the efficiency of your mower.

6.Keep cable away from lawnmower, always work away from the power point mowing up and down, never in circles.

7.Do not pull cable around sharp objects.

8.Always switch off at the mains before disconnecting any plug, cable connector or extension cable.

9.Switch off, remove plug from mains and examine electric supply cable for damage or ageing before winding cable for storage. Do not repair a damaged cable, replace it

with a new one. Use only Flymo replacement cable. 10.Always wind cable carefully, avoiding kinking.

11. Never carry the product by the cable.

12.Never pull on the cable to disconnect any of the plugs. 13.Use only on AC mains supply voltage shown on the

product rating label.

14.Our products are double insulated to EN60335. Under no circumstance should an earth be con- nected to any part of the product.

Preparation

1.While using your product, always wear substantial footwear and long trousers.

2.Make sure the lawn is clear of sticks, stones, bones, wire and debris; they could be thrown by the blade.

3.Before using the machine and after any impact, check for signs of wear or damage and repair as necessary.

4.Replace worn or damaged blades together with their fixings in sets to preserve balance.

Use

1.Use the lawnmower only in daylight or good artificial light.

2.Avoid operating your lawnmower in wet grass, where feasible.

3.Take care in wet grass, you may lose your footing.

4.On slopes, be extra careful of your footing and wear non-slip footwear.

5.Mow across the face of slopes, never up and down.

6.Exercise extreme caution when changing direction on slopes. Walk never run.

7.Mowing on banks and slopes can be dangerous. Do not mow on banks or steep slopes.

8.Do not walk backwards when mowing, you could trip.

9.Never cut grass by pulling the mower towards you. 10.Switch off before pushing the mower over surfaces

other than grass.

11.Never operate the lawnmower with damaged guards or without guards in place.

12.Keep hands and feet away from the cutting means at all times and especially when switching on the motor.

13.Do not tilt lawnmower when the motor is running, except when starting and stopping. In this case, do not tilt more than absolutely necessary and lift only the part which is away from the operator. Always ensure that both hands are in the operating position before returning the appliance to the ground.

14.Never pick up or carry a mower when it is operating or still connected to the mains supply.

15.Remove the plug from the mains :

- before leaving the mower unattended for any period; - before clearing a blockage;

- before checking, cleaning or working on the appliance; - if you hit an object. Do not use your lawnmower

until you are sure that the entire lawnmower is in a safe operating condition;

- if the lawnmower starts to vibrate abnormally. Check immediately. Excessive vibration can cause injury.

Maintenance and storage

1.Keep all nuts, bolts and screws tight to be sure the lawnmower is in safe working condition.

2.Check the grassbox/grassbag frequently for wear or deterioration.

3.Replace worn or damaged parts for safety.

4.Only use the replacement blade, blade bolt, spacer and impeller specified for this product.

5.Be careful during adjustment of the lawnmower to prevent entrapment of the fingers between moving blades and fixed parts of the machine.

Cables

CABLES

IMPORTANT

•Use only 1.00mm2 size cable up to 40 metres length maximum.

Maximum rating : 1 . 00mm2 size cable, 10 amps 250 volts AC .

•THE TURBO COMPACT IS SUPPLIED WITH AN ELECTRIC MAINS CABLE FITTED WITH A

FEMALE CONNECTOR

1.Flymo Mains Cables and Extension Cables are available from your local Approved Service Centre.

2.Do not wire an extension cable directly to your product yourself. Please contact your local Approved Service Centre for further information on the connectors and kits available.

3.Only use extension cables specifically designed for outdoor use.

CONNECTORS

IMPORTANT

•Flymo connectors are suitable for use with 2 core cable only. Under no circumstances should these connectors be used for earthed products.

•All Flymo connectors and cables are of splashproof con- struction. They are not waterproof and must not be left outside permanently nor should they be submerged or

immersed in water. Do not let cable lay or trail through pools of water or splashed with water from hose pipes.

MAINS PLUG REPLACEMENT

IMPORTANT

•If the plug supplied is cut off it should be destroyed. There is an electric shock hazard if a

cut off plug is inserted into a 13 amp socket.

1. No earth required. Flymo products are double insulated

to EN60335 and under no circumstances should an earth be connected to any part of the product.

2.Ensure the mains voltage suits your product

3.IMPORTANT!

The wires in the mains lead are coloured in accor- dance with the following code:

BLUE - NEUTRAL BROWN - LIVE

The wire which is coloured BLUE must be connect- ed to the Terminal which is marked with the letter 'N' or coloured BLACK.

The wire which is coloured BROWN must be con- nected to the Terminal which is marked with the let- ter 'L' or coloured RED.

4.It is important that the outer sheath is clamped cor- rectly into the 3-pin plug.

5.If in doubt consult your local Service Repairer or qualified electrician before the machine is used.

6.A 13 Amp fuse must be fitted to the Mains Plug.

7.The normal plug fuse and household fuse only pro- tect the electrical equipment and are not a safe- guard against electrocution.

If your product is hard wired i.e. non-detachable mains electric cable, a conversion kit and exten- sion cable is available from all Approved Service Centres which can be found in your local Yellow Pages.
